170ARM37030

170ARM37030

Discrete I/O Module Modicon Momentum - 10I / 8O Relay
Available - call for stock

Free 2 Day Shipping
1 year warranty

Categories

Part Number170ARM37030
ManufacturerSchneider Electric
SeriesModicon Communication
Weight1lb
TypeIO Modules
Warranty1 year
Width5.57 in (141.5 mm)
Range of productModicon Momentum automation platform
Product or component typeDiscrete relay I/O base AC
Group of channels2 groups of 4 outputs
1 group of 10 inputs
Discrete input number10 IEC 1131-2 Type 1
Discrete input logicPositive
Discrete input voltage24...230 V AC
Discrete output number8
Discrete output typeRelay normally open
Discrete output voltage24...230 V AC
Protective treatmentTC
[Us] rated supply voltage120 V AC
Input voltage limits- 3...30 V
Voltage state 0 guaranteed-3...5 V
Voltage state1 guaranteed11...30 V
Current state 0 guaranteed<= 1.2 mA
Current state 1 guaranteed>= 2.5 mA
Input resistance4 kOhm
Discrete output current<= 0.15 mA 115 V inductive
<= 0.5 mA 115 V resistive
<= 1 mA 24 V inductive
<= 2 mA 24 V resistive
>= 0.005 A 24 V
Output overload protectionExternal by varistor in parallel with each contact
Output short-circuit protectionExternal by varistor in parallel with each contact
Mechanical durability<= 30000000 cycles
Electrical durability<= 100000 cycles inductive
Response time2.2 ms from state 0 to state 1 on input
3.3 ms from state 1 to state 0 on input
10 ms 60 Hz from state 0 to state 1 on output
10 ms 60 Hz from state 1 to state 0 on output
Isolation between output channels group1780 V AC
Isolation between group of I/O channels1780 V AC
Isolation between channels and bus500 V AC
Power dissipation<= 8.5 W
5.5 W
Protection typeWithout protection
Associated fuse rating4 A fast blow operating voltage
MarkingCE
Terminals description PLC n°1(2)IN_DIS#2
(5)IN_DIS#5
(6)IN_DIS#6
(8)IN_DIS#8
(10)IN_DIS#10
(9)IN_DIS#9
(N)PW
(L1)PW
(3)IN_DIS#3
(7)IN_DIS#7
TB
(4)IN_DIS#4
(1)IN_DIS#1
Terminals description PLC n°2(3)OUT_DIS#3
(6)OUT_DIS#6
(2L1)PW
TB_1
(1)OUT_DIS#1
(8)OUT_DIS#8
(2)OUT_DIS#2
(5)OUT_DIS#5
(7)OUT_DIS#7
(4)OUT_DIS#4
(1L+)PW
Current consumption5 mA 120 V AC
Depth1.87 in (47.5 mm)
Height5.57 in (141.5 mm)
