Siemens 6ES7216-2AD23-0XB0

Siemens 6ES7216-2AD23-0XB0 – SIMATIC S7-200 CPU 226

The Siemens 6ES7216-2AD23-0XB0 is a powerful and compact CPU module designed for industrial automation using the SIMATIC S7-200 system. This model, the CPU 226, offers a high-performance, space-efficient solution for controlling processes and machinery in standalone and networked environments. With built-in input/output capabilities and expandable memory, the CPU 226 is the central intelligence for automation setups requiring speed, reliability, and flexibility.

Compact Yet Powerful Automation Control

The CPU 226 features a compact form factor that allows integration into control panels or confined spaces easily without sacrificing functionality. It provides 24 digital inputs and 16 digital outputs, all operating on DC voltage, allowing direct connection to a wide range of sensors and actuators commonly used in industrial applications. This eliminates the need for additional I/O expansion modules in many use cases, simplifying system design and reducing costs.

Generous Memory and Dual Communication Ports

Equipped with a sizable 16/24 KB of program memory and 10 KB of data memory, the 6ES7216-2AD23-0XB0 supports complex control strategies and user-defined data handling. Whether your application requires data logging, advanced processing, or decision-making logic, this CPU delivers the storage and speed necessary to execute tasks efficiently. Additionally, it includes two PPI (Point-to-Point Interface) ports that double as user-programmable communication interfaces. This dual-port configuration enhances flexibility in networked environments and seamlessly integrates with Human Machine Interfaces (HMIs), programming devices, or other PLCs.

Reliable Performance for Demanding Environments

Built for industrial reliability, the CPU 226 can operate in harsh conditions, including electrical noise, temperature fluctuations, and vibration-prone areas. It meets Siemens' rigorous quality and safety standards, making it suitable for manufacturing, processing, and infrastructure automation deployment. The integrated features and robust design ensure consistent performance in 24/7 operations, minimizing downtime and improving overall system efficiency.

Scalability and Expandability

Although compact, the CPU 226 is part of the flexible S7-200 family and supports I/O expansion for applications requiring more extensive control capabilities. Expansion modules can be added as needed, allowing the CPU to grow alongside system demands. Additionally, its communication capabilities support integration with PROFIBUS DP networks via an external adapter, making it suitable for standalone and networked installations.

Frequently Asked Questions (FAQ)

What does the Siemens 6ES7216-2AD23-0XB0 CPU control?

It controls industrial automation processes, handling sensor inputs and sending outputs to actuators for logic-based operations.

How many I/O points does it have?

This CPU provides 24 digital inputs and 16 digital outputs, all operating on DC voltage.

Is this module programmable?

It is programmable using Siemens STEP 7-Micro/WIN software designed explicitly for the S7-200 series.

Can I use this CPU in networked systems?

Yes, with its two communication ports and optional PROFIBUS DP support, it can be networked with other devices or controllers.

How much program and data memory is available?

It has 16 or 24 KB of program memory (depending on configuration) and 10 KB of data memory.

What voltage does the CPU operate on?

It runs on a standard DC power supply, making it suitable for many industrial electrical setups.

Is this CPU expandable?

You can add digital and analog expansion modules to increase I/O capacity and functionality.

What programming software is compatible?

Siemens STEP 7-Micro/WIN is the software for programming S7-200 CPUs like this one.

Is this model suitable for harsh environments?

Yes, it's designed for industrial applications and is resistant to vibration, temperature changes, and electrical interference.

What kind of warranty is provided by MRO Electric and Supply?

MRO Electric offers a 2-year warranty and free shipping, ensuring quality and value with every purchase.
