Siemens 6ES7223-1PH22-0XA0

Siemens 6ES7223-1PH22-0XA0  Product Overview

The Siemens 6ES7223-1PH22-0XA0 is a versatile I/O module from the SIMATIC S7-1200 series, engineered to provide seamless digital input and output integration in various automation systems. Designed with reliability and simplicity, this module offers eight digital inputs and eight digital outputs, making it ideal for compact machines, distributed control systems, and modular automation setups. It supports efficient signal processing in industrial and commercial environments with robust electrical specifications and compatibility with Siemens controllers.

Input and Output Capabilities

This module provides eight digital inputs and eight digital outputs, allowing users to easily connect sensors, switches, actuators, relays, and other field devices. The input channels operate at 24 VDC, ensuring quick and reliable detection of control signals from devices such as push buttons, limit switches, and proximity sensors. On the output side, the module supports switching voltages up to 250 VAC, providing the flexibility needed to control devices like lights, solenoids, and contactors within a range of voltage requirements.

Electrical and Performance Specifications

Engineered for durability and performance, the Siemens 6ES7223-1PH22-0XA0 features high-speed signal processing and stable electrical connections. Each input and output channel is designed to handle industrial-grade signal integrity, reducing the risk of noise interference or signal loss. The wide voltage tolerance and built-in protection mechanisms allow the module to operate reliably in diverse conditions, ensuring long-term performance in continuous automation tasks.

System Integration and Compatibility

This I/O module is specifically designed for seamless integration with Siemens SIMATIC S7-1200 controllers but is also compatible with broader Siemens TIA Portal environments. Installation is simplified through standard DIN rail mounting, and the system's internal bus facilitates communication with the CPU, which requires no external wiring. This plug-and-play design minimizes installation time while ensuring a clean and organized control panel layout.

Warranty and Availability

Offered by MRO Electric and Supply, the Siemens 6ES7223-1PH22-0XA0 comes with a 2-year warranty for added confidence and long-term assurance. It is available for immediate shipping, with free delivery to expedite your automation project and reduce downtime. With Siemens' industry-leading build quality and MRO Electric's responsive service, this I/O module is a dependable choice for upgrading or expanding any control system.

FAQs about the Siemens 6ES7223-1PH22-0XA0

What kind of inputs and outputs does this module support?

It includes eight digital inputs operating at 24 VDC and eight digital outputs that can switch up to 250 VAC.

Is this module compatible with the S7-1200 PLC?

It is fully compatible with Siemens S7-1200 PLCs and integrates easily into the TIA Portal environment.

Can it be used in both industrial and commercial automation?

Absolutely. It is designed for versatile use in compact industrial machines, building automation, and other control applications.

What mounting options are available?

The module is DIN rail mountable, allowing for quick and secure installation in control panels.

Does it require separate wiring for communication?

No, it connects to the S7-1200 controller via the internal system bus, so no additional communication wiring is necessary.

Can the outputs switch AC loads?

The digital outputs can handle switching voltages up to 250 VAC, making them suitable for various devices.

Is the module protected against electrical interference?

It includes built-in protections to ensure stable performance even in electrically noisy environments.

What types of field devices can be connected?

Devices like sensors, actuators, lights, solenoids, and relays can directly connect to the inputs and outputs.

How is the module configured?

Configuration is done through Siemens' TIA Portal software, providing easy setup and integration into control logic.

Is it available right away?

MRO Electric has this module in stock and is ready to ship immediately. It offers free shipping and a 2-year warranty.
