Siemens 6SL3100-1DE22-0AA1

SINAMICS S120 DRIVE SYSTEM BOOKSIZE CONTROL SUPPLY, 3PH - 380-480V AC, 20A

5/5
1 rating

Select Condition

Refurbished

1 in stock

New

2 in stock

$1,483.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number6SL3100-1DE22-0AA1
ManufacturerSiemens
TypeAC Drives
Model #6SL31001DE220AA1
Warranty2 Year
CategoryControl Supply
ConstructionBooksize
Voltage510-72- VDC
Output24.0 ... 28.8 V
Max input current2 Amps
Rated current (600 V DC)1.1 A
Output current20 Amps
24 V busbars carrying capacity20 Amps
DC link busbars current cap100 Amps
Width 1.97 in
Height 14.96 in
Depth10.63 in
TerminalScrew-type
PE conductorM5 Screw
RI suppressionCategory C2 in accordance with EN 61800-3

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 6SL3100-1DE22-0AA1 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 6SL3100-1DE22-0AA1 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 6SL3100-1DE22-0AA1, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 10lbs

Want it shipped tomorrow?

  • Order within the next 23 hours and 41 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 6SL3100-1DE22-0AA1 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Siemens 6SL3100-1DE22-0AA1 Overview

Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply: An Overview

The Siemens 6SL3100-1DE22-0AA1 is a high-performance control supply module from Siemens designed for integration into advanced industrial automation systems. As part of the SINAMICS family, it plays a vital role in managing the power requirements of control systems, ensuring stable and reliable operation. This compact and efficient module is built with Siemens' renowned engineering quality, offering robust performance, flexibility, and ease of installation. Available with a 2-year warranty from MRO Electric and Supply and benefiting from free shipping, this control supply unit is an excellent choice for professionals seeking reliability in their power management systems.

Key Features of the 6SL3100-1DE22-0AA1

Input and Output Specifications

The Siemens 6SL3100-1DE22-0AA1 operates on an input voltage range of 510 to 720 VDC, making it highly adaptable to various industrial applications that demand stable DC input. With a maximum input current of 2 Amps, it efficiently manages the power conversion process, ensuring that the control system is consistently supplied with the necessary power. On the output side, this unit delivers 24 to 28.8 VDC, providing adequate power for downstream components in automation systems. The rated current of 1.1 A at 600 VDC ensures the module can handle moderate power loads without compromising performance.

High Current Capacities

The Siemens 6SL3100-1DE22-0AA1 is designed to handle substantial current loads, making it suitable for demanding industrial environments. Its output current capacity is 20 Amps, which is sufficient for supplying power to control systems and other essential components in an automation setup. Furthermore, the 24 V busbars are rated for 20 Amps, while the DC link busbars can carry up to 100 Amps, ensuring that the module can handle high current demands without overheating or causing voltage drops. These high capacities make the module suitable for heavy-duty applications requiring continuous power supply and stability.

Compact and Efficient Design

This control supply module features a booksize construction, which is ideal for installations where space is limited. It fits seamlessly into control cabinets or confined spaces with dimensions of 1.97 inches in width, 14.96 inches in height, and 10.63 inches in depth. This compact design makes it an excellent choice for machine builders and system integrators who need to optimize space while ensuring robust performance. The small footprint and high power capacity deliver a perfect balance of efficiency and functionality for industrial automation systems.

Terminals and Connections

The Siemens 6SL3100-1DE22-0AA1 comes with screw-type terminals, providing secure and reliable connections that are easy to install and maintain. This connection method is a standard in the industry, ensuring compatibility with various wiring configurations. Additionally, the module is equipped with an M5 screw for the PE (Protective Earth) conductor, ensuring safe and efficient grounding, which is essential for minimizing electrical hazards and ensuring system stability.

RI Suppression and Compliance

The Siemens 6SL3100-1DE22-0AA1 complies with Category C2 requirements per EN 61800-3.

FAQ for the Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply

What is the RI suppression category of the Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply?

The Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply is classified under Category C2 for RI suppression by EN 61800-3. This means the module meets the electromagnetic compatibility (EMC) standards for industrial environments, ensuring that it minimizes electromagnetic interference (EMI) and radio frequency interference (RFI). Category C2 is suitable for use in industrial environments with restricted access, where interference levels are tightly controlled to prevent other sensitive electronic equipment disruption. This classification ensures that the control supply operates reliably without causing or being affected by unwanted electromagnetic emissions.

What is the input voltage range of the Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply?

The Siemens 6SL3100-1DE22-0AA1 operates within an input voltage range of 510 to 720 VDC. This range allows the unit to function reliably in industrial environments that require stable DC input for powering control systems and automation components.

What is the maximum output voltage of the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1's maximum output voltage is 28.8 VDC, with a minimum output of 24 VDC. This output provides sufficient power for downstream automation components that rely on stable 24V power supplies.

What is the maximum input current for the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1's maximum input current is 2 Amps. This rating ensures the module can efficiently handle the required power intake for proper functionality without overloading.

What is the rated current for the Siemens 6SL3100-1DE22-0AA1 at 600 V DC?

The Siemens 6SL3100-1DE22-0AA1's rated current at 600 V DC is 1.1 Amps. This specification ensures the module can maintain stable performance even when running at higher input voltages.

What is the maximum output current of the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1's maximum output current is 20 Amps. This high current capacity allows the module to power several control components within a system, making it suitable for applications requiring a robust power supply.

What is the 24 V busbar current carrying capacity of the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1's 24 V busbars have a current carrying capacity of 20 Amps. This ensures stable power distribution across the connected components, supporting the unit’s performance in complex automation systems.

What is the DC link busbar current capacity of the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1's DC link busbars have a current capacity of 100 Amps. This high capacity allows the unit to handle significant current demands in industrial setups, ensuring a reliable connection to the DC link.

What are the dimensions of the Siemens 6SL3100-1DE22-0AA1 AC Drive Control Supply?

The Siemens 6SL3100-1DE22-0AA1 is 1.97 inches high, 14.96 inches wide, and 10.63 inches deep. These compact dimensions allow easy integration into space-constrained control panels or automation systems.

What type of terminals are used in the Siemens 6SL3100-1DE22-0AA1?

The Siemens 6SL3100-1DE22-0AA1 is equipped with screw-type terminals. These terminals offer secure and easy wiring connections and ensure reliable electrical contacts in industrial environments.

What kind of grounding does the Siemens 6SL3100-1DE22-0AA1 require?

The Siemens 6SL3100-1DE22-0AA1 uses an M5 screw for grounding the PE (Protective Earth) conductor. Proper grounding is essential to ensure electrical safety and prevent potential hazards, especially in industrial applications.
