Siemens 6SL3120-1TE24-5AA3

The Siemens SINAMICS S120 AC Drive, with part number 6SL3120-1TE24-5AA3, is a comprehensive drive system that is designed for use in mechanical and plant engineering applications. It is suitable for a wide range of drive tasks, including simple pump and fan applications in the process industry, and complex individual drives in centrifuges, presses, extruders, elevators, and conveyor and transport systems. The SINAMICS S120 is also suitable for highly dynamic servo drives in machine tools, packaging, and printing machines. It is capable of driving motors with a voltage range of 510-720V DC and a power rating of up to 24 kW (30 horsepower). These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.

Features

The SINAMICS S120 is available in a "booksize" format, which is optimized for multi-axis applications and is designed to be mounted adjacent to one another. The booksize format has dimensions of 5.91 inches in width, 3.94 inches in base, and 4.13 inches in height. It offers various cooling options, including internal air cooling, external air cooling, and cold-plate cooling. The booksize format also includes an integral connection for the shared voltage-source DC link.
The SINAMICS S120 includes Motor Modules, which convert energy from the DC link for the connected motors with variable voltage and variable frequency. The Motor Modules are available in single and double types, with current ratings ranging from 3 A to 200 A for single modules and 3 A to 18 A for double modules. The Motor Modules have internal and external air cooling options and are short-circuit and ground-fault proof. They also include an integrated DC link and electronics current busbar connection, as well as an integrated "safe motor brake control" feature. The Motor Modules are equipped with an electronic type plate and LED indicators for the operating status and error status. They also have a DRIVE-CLiQ interface for communication with the Control Unit and other components in the drive line-up.

Application

The SINAMICS S120 also includes a Control Unit that carries out all drive and technological functions across all axes. The Control Unit is connected to the Motor Modules via DRIVE-CLiQ, and stores the open-loop and closed-loop control functions for the Motor Modules. In addition, supplementary system components are available to enhance functionality and provide different interfaces for encoders and process signals. These components include line-side power components, such as fuses, contactors, reactors, and filters for switching the power supply and meeting EMC requirements. There are also Line Modules, which supply power centrally to the DC link, as well as optional DC link components that stabilize the DC link voltage.

Installation

The SINAMICS S120 components are designed for installation in cabinets and are easy to handle and install, with a practical connection system and standardized design. They are also equipped with internal air cooling, with other cooling methods available on request. The SINAMICS S120 drive system is designed to be seamlessly integrated into your mechanical and plant engineering applications, offering reliable and efficient performance.
In summary, the Siemens SINAMICS S120 AC Drive, with part number 6SL3120-1TE24-5AA3, is a versatile and comprehensive drive system that is suitable for a wide range of mechanical and plant engineering applications. It is available in a compact "booksize" format and offers a variety of cooling options, as well as powerful Motor Modules and a Control Unit for enhanced functionality and performance. Its wide voltage range and high power rating make it suitable for a variety of applications, and its robust design ensures reliable operation in demanding environments.

Contact Us Today For More Information About Siemens Products

Check out the rest of our Siemens product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like 6SL3120-1TE24-5AA3, take a look at more from our AC Drives line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our 6SL3120-1TE24-5AA3 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
