ABR7S33

Schneider Electric ABR7S33

ABR7S33

PLug-In Electromechanical Relay - 12.5 Mm - 24 V DC - 1 Co
2 year warranty
Call (800) 691-8511 for pricing
Request Quote

Testimonials

Additional Information

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means cheaper prices and better service for you. For more products like ABR7S33, take a look at more from our Modicon Communication line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.

Specifications

ManufacturerSchneider Electric
SeriesModicon Communication
[Uimp] rated impulse withstand voltage2.5 kV conforming to IEC 60947-1
Range of productAdvantys Telefast ABE7
Product or component typePlug-in electromechanical relay
Control circuit typeDC
Quantity per setSet of 4
Width pitch dimension12 mm
Product compatibilityABE7P08T330
ABE7P08T330E
ABE7P16T318
ABE7P16T318E
ABE7P16T330
ABE7P16T330E
ABE7P16T332
ABE7P16T334
ABE7R16T330
ABE7R16T332
[Uc] control circuit voltage24 V
[Ith] conventional free air thermal current10 A
Contacts type and composition1 C/O
Threshold tripping voltage16.8 V at 40 °C
Drop-out voltage3.6 V at 20 °C
Drop-out current3.5 mA at 20 °C
Power dissipation per pole<= 0.6 W
Associated fuse rating1 A fast blow
Maximum switching voltage264 V AC 50/60 Hz conforming to IEC 60947-5-1
130 V DC conforming to IEC 60947-5-1
Electrical durability500000 cycles, maximum switching current: 3000 mA at 24 V DC-12
500000 cycles, maximum switching current: 3000 mA at 230 V AC-12
500000 cycles, maximum switching current: 1700 mA at 230 V AC-15
500000 cycles, maximum switching current: 1400 mA at 24 V DC-13 10 ms
Minimum switching current100 mA at >= 5 V
Electrical reliability1e-008
Operating rate in Hz0.5 Hz at Ie
5 Hz no load
Mechanical durability20000000 cycles
