ABR7S37

ABR7S37

PLug-In Electromechanical Relay - 12.5 Mm - 24 V DC - 2 Co
Available - call for stock

2 year warranty

Categories

Part NumberABR7S37
ManufacturerSchneider Electric
SeriesModicon Communication
Weight1lb
TypeBases
Warranty2 year
[Uimp] rated impulse withstand voltage2.5 kV conforming to IEC 60947-1
Range of productAdvantys Telefast ABE7
Product or component typePlug-in electromechanical relay
Control circuit typeDC
Quantity per setSet of 4
Width pitch dimension12 mm
Product compatibilityABE7R16T370
[Uc] control circuit voltage24 V
[Ith] conventional free air thermal current8 A
Threshold tripping voltage16.8 V at 40 °C
Drop-out voltage3.6 V at 20 °C
Drop-out current3.5 mA at 20 °C
Power dissipation per pole<= 0.6 W
Associated fuse rating1 A fast blow
Maximum switching voltage264 V AC 50/60 Hz conforming to IEC 60947-5-1
130 V DC conforming to IEC 60947-5-1
Electrical durability500000 cycles, maximum switching current: 2500 mA at 24 V DC-12
500000 cycles, maximum switching current: 2500 mA at 230 V AC-12
500000 cycles, maximum switching current: 1300 mA at 230 V AC-15
500000 cycles, maximum switching current: 1000 mA at 24 V DC-13 10 ms
Minimum switching current100 mA at >= 5 V
Electrical reliability1e-008
Operating rate in Hz0.5 Hz at Ie
5 Hz no load
Mechanical durability20000000 cycles
