|[Uimp] rated impulse withstand voltage||2.5 kV conforming to IEC 60947-1|
|Range of product||Advantys Telefast ABE7|
|Product or component type||Plug-in electromechanical relay|
|Control circuit type||DC|
|Quantity per set||Set of 4|
|Width pitch dimension||0.47 in (12 mm)|
|[Uc] control circuit voltage||48 V|
|[Ith] conventional free air thermal current||8 A|
|Threshold tripping voltage||16.8 V at 104 Â°F (40 Â°C)|
|Drop-out voltage||3.6 V at 68 Â°F (20 Â°C)|
|Drop-out current||3.5 mA at 68 Â°F (20 Â°C)|
|Power dissipation per pole||<= 0.6 W|
|Associated fuse rating||1 A|
|Maximum switching voltage||130 V DC conforming to IEC 60947-5-1|
|264 V AC 50/60 Hz conforming to IEC 60947-5-1|
|Electrical durability||500000 cycles, maximum switching current: 1400 mA at 24 V DC-13 10 ms|
|500000 cycles, maximum switching current: 1700 mA at 230 V AC-15|
|500000 cycles, maximum switching current: 3000 mA at 230 V AC-12|
|500000 cycles, maximum switching current: 3000 mA at 24 V DC-12|
|Minimum switching current||100 mA at >= 5 V|
|Operating time||<= 13 ms between coil de-energisation and NO opening|
|<= 13 ms between coil energisation and NO closing|
|Contact bounce time||<= 1.6 ms 1 NO|
|<= 5.5 ms 1 NC|
|Operating rate in Hz||5 Hz no load|
|0.5 Hz at Ie|
|Mechanical durability||20000000 cycles|
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed ABR7S33E to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this ABR7S33E we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty ABR7S33E, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty ABR7S33E for credit when ordering from MRO Electric
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Bases from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at firstname.lastname@example.org, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ABR7S33E, take a look at more from our Bases line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our ABR7S33E products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
