Schneider Electric AS-B825-016


ASB825016 - 800-Series I/O Module, Discrete In, 24 Vdc (TH), 16 pnts, 8 pnts per common

5 new in stock
1 year warranty
Call (800) 691-8511 for pricing
Click for Quote


Additional Information

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like AS-B825-016, take a look at more from our Modicon 984 Series line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.


ManufacturerSchneider Electric
SeriesModicon 984 Series
FusingOne per group
Description24 Vdc input
Type of OperationTrue High
Number of Points16
Operating Voltage20 ... 28 Vdc
Number of Groups1
Inputs per Group16
Max. Input Voltage
Continuous30 Vdc
Surge500 Vdc for 3 ms
ON Conditions< 1000 Ω
OFF Conditions> 25,000 Ω
Wetting Current6 mA (typical) @ 24 Vdc
Max Response Time
OFF to ON11 ms (2.5 ms typical)
ON to OFF11 ms (2.5 ms typical)
Power Required
+5 V27 mA
+4.3 V2 mA
5 V15 mA
External Power Supply24± 4 Vdc, 200 mA
Space Required1 slot
Weight2.75 lbs (1.25 kg)
