ATV32HU15N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV32HU15N4

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Variable speed drive ATV32 - 1.5 kw - 400 V - 3 phase - with heat sink
PRODUCT TYPE INFO: Altivar 32


1 in stock

Ships Today


Free Shipping

2 Year warranty

Part NumberATV32HU15N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
RangeAltivar 32
CategoryVariable speed drive
Descriptionfor complex machines
Assemblywith heat sink
FilterClass C2 EMC filter integrated
DestinationAsynchronous motors Synchronous motors
Phase3phase
Supply frequency50...60 Hz - 5...5 %
Supply voltage380...500 V - 15...10 %
Network frequency47.5...63 Hz
Line current4.9 A 500 V 3 phases 1.5 kW 2 hp 6.5 A 380 V 3 phases 1.5 kW 2 hp
Nominal output current4.1 A 4 kHz 500 V 1.5 kW 2 hp
Motor power kW1.5 kW 380...480 V
Prospective line Isc<= 5 kA 3 phases
Motor power hp2 hp 380...480 V
Output frequency0.0005...0.599 kHz
Switching frequency2...16 kHz adjustable

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV32HU15N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV32HU15N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV32HU15N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 6lbs

Want it shipped today?

  • Order within the next hour.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV32HU15N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV32HU15N4 Overview

Schneider Electric ATV32HU15N4: A Comprehensive Overview

Main Specifications:

The ATV32HU15N4 belongs to the Altivar 32 range, designed as a variable-speed drive for both asynchronous and synchronous motors. This section covers its primary specifications, including voltage range, frequency, and motor power capacity.

Key Functions and Features

Motor Control Profiles:

Highlighting the versatility of the ATV32HU15N4, this section covers the different motor control profiles supported, including voltage/frequency ratio with 2 or 5 points, flux vector control without a sensor, and synchronous motor control through vector control without a sensor.

Connectivity and Signaling:

Exploring the drive's connectivity options through removable screw terminals, internal supply features, and local signaling LEDs. This section emphasizes the drive's adaptability to various analog and discrete inputs and outputs.

Compact Design and Dimensions:

Focusing on the physical characteristics of the ATV32HU15N4, including its compact dimensions, weight, and ease of installation. This section provides a visual representation of the drive's form factor.

Environmental Compliance and Certifications:

Examining the drive's adherence to environmental standards, certifications, and its suitability for different operating conditions. This section underscores its compliance with standards such as EN 55011, EN 61800-3, and others.

Installation and Operation:

Detailing the drive's suitability for ambient air temperatures, storage conditions, operating altitudes, and installation orientations. This section guides users on the optimal environmental conditions for the drive's efficient operation.

FAQs - Schneider Electric ATV32HU15N4

Q1: What is the range of products to which the ATV32HU15N4 belongs?

A: The ATV32HU15N4 is part of the Altivar 32 range of variable speed drives.

Q2: What types of motors are compatible with the ATV32HU15N4?

A: The drive is designed for use with both asynchronous and synchronous motors.

Q3: What are the key functions available in the ATV32HU15N4?

A: The drive offers various functions, including an integrated Class C2 EMC filter, speed control capabilities, and motor control profiles.

Q4: Can the ATV32HU15N4 handle complex machines?

A: Yes, the drive is specifically suited for applications involving complex machines.

Q5: What is the voltage range for the ATV32HU15N4?

A: The rated supply voltage ranges from 380 to 500 V with limits between 323 and 550 V.

Q6: What is the speed range for asynchronous motors in open-loop mode?

A: The speed range is 1 to 100 for asynchronous motors in open-loop mode.

Q7: What are the dimensions of the ATV32HU15N4?

A: The drive measures 1.77 inches in width, 12.8 inches in height, and 9.65 inches in depth, weighing 5.51 pounds.

Q8: How is the ATV32HU15N4 protected against overcurrent and overheating?

A: The drive provides protection against input phase breaks, overcurrent between output phases and earth, overheating, short-circuit between motor phases, and thermal protection.

Q9: What communication protocols does the ATV32HU15N4 support?

A: The drive supports CANopen and Modbus communication protocols.

Q10: What certifications does the ATV32HU15N4 hold?

A: The drive is certified by CSA, C-Tick, GOST, NOM 117, and UL, with CE marking.

Q11: Can the ATV32HU15N4 be used in different ambient temperatures?

A: Yes, the drive can operate in ambient temperatures ranging from -10 to 50 °C without derating.

Q12: How many analog and discrete inputs does the ATV32HU15N4 have?

A: The drive features 3 analog inputs and 7 discrete inputs.

Q13: Does the ATV32HU15N4 provide any environmental protections?

A: The drive has an IP20 degree of protection according to EN/IEC 61800-5-1.

Q14: What is the noise level of the ATV32HU15N4?

A: The noise level is 43 dB according to 86/188/EEC.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
