ATV61HD30N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV61HD30N4

Rated 5/5 on 3 reviews

Rate this product


MANUFACTURER: Schneider Electric

DESCRIPTION: 61 30 kW 40 HP 480 Volt 3-Phase EMC IP20

PRODUCT TYPE INFO: Altivar 61

3 in stock

Ships Today


2 Year warranty

Part NumberATV61HD30N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
Range of productAltivar 61
66 A for 380 V 3 phases 30 kW / 40 hp
12...16 kHz with derating factor
Voltage/frequency ratio - Energy Saving, quadratic U/f
Voltage/frequency ratio, 2 points
Flux vector control without sensor, standard
Modbus
Communication card for BACnet
Communication card for CC-Link
Controller inside programmable card
Communication card for DeviceNet
Communication card for EtherNet/IP
Communication card for Fipio
I/O extension card
Communication card for Interbus-S
Communication card for LonWorks
Communication card for METASYS N2
Communication card for Modbus Plus
Communication card for Modbus TCP
Communication card for Modbus/Uni-Telway
Multi-pump card
Communication card for Profibus DP
Communication card for Profibus DP V1
Product or component typeVariable speed drive
Product specific applicationPumping and ventilation machine
Component nameATV61
Motor power kW30 kW, 3 phases at 380...480 V
Motor power hp40 hp, 3 phases at 380...480 V
Power supply voltage380...480 V - 15...10 %
Supply number of phases3 phases
Line current56 A for 480 V 3 phases 30 kW / 40 hp
EMC filterLevel 3 EMC filter
Assembly styleWith heat sink
Apparent power43.4 kVA at 380 V 3 phases 30 kW / 40 hp
Maximum prospective line Isc22 kA for 3 phases
Maximum transient current79.2 A for 60 s, 3 phases
Nominal switching frequency12 kHz
Switching frequency1...16 kHz adjustable
Asynchronous motor controlVoltage/frequency ratio, 5 points
Synchronous motor control profileVector control without sensor, standard
Communication port protocolCANopen
Type of polarizationNo impedance for Modbus
Option cardCommunication card for APOGEE FLN
