ATV71HU15M3

ATV71HU15M3

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Variable speed drive ATV71 - 1.5kW-2HP - 240V - EMC filter-graphic terminal
PRODUCT TYPE INFO: Altivar 71


1 in stock
Ships Today

Free Shipping
2 Year warranty

Categories

Part NumberATV71HU15M3
ManufacturerSchneider Electric
SeriesAltivar 71
Model #ATV71HU15M3
TypeAC Drives
Warranty2 Year
Range of productAltivar 71
1.5 kW, 3 phases at 200...240 V
2 hp, 3 phases at 200...240 V
100 m unshielded cable
Single phase
12 A for 200 V single phase 0.75 kW / 1 hp
9.6 A for 240 V 3 phases 1.5 kW / 2 hp
9.9 A for 240 V single phase 0.75 kW / 1 hp
4 kVA at 240 V 3 phases 1.5 kW / 2 hp
5 kA for single phase
8 A at 4 kHz 230 V 3 phases 1.5 kW / 2 hp
7.9 A for 2 s single phase 0.75 kW / 1 hp
12 A for 60 s 3 phases 1.5 kW / 2 hp
13.2 A for 2 s 3 phases 1.5 kW / 2 hp
4...16 kHz with derating factor
Flux vector control (FVC) with sensor (current vector)
Sensorless flux vector control (SFVC) (voltage or current vector)
ENA (Energy adaptation) system for unbalanced loads
Product or component typeVariable speed drive
Product specific applicationComplex, high-power machines
Component nameATV71
Motor power kW0.75 kW, single phase at 200...240 V
Motor power hp1 hp, single phase at 200...240 V
Maximum motor cable length50 m shielded cable
Power supply voltage200...240 V - 15...10 %
Network number of phases3 phases
Line current11.3 A for 200 V 3 phases 1.5 kW / 2 hp
EMC filterIntegrated
Assembly styleWith heat sink
Apparent power2.4 kVA at 240 V single phase 0.75 kW / 1 hp
Prospective line Isc5 kA for 3 phases
Nominal output current4.8 A at 4 kHz 230 V single phase 0.75 kW / 1 hp
Maximum transient current7.2 A for 60 s single phase 0.75 kW / 1 hp
Output frequency0.1…599 Hz
Nominal switching frequency4 kHz
Switching frequency1...16 kHz adjustable
Asynchronous motor control profileVoltage/frequency ratio (2 or 5 points)
Type of polarizationNo impedance for Modbus

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV71HU15M3 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV71HU15M3 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV71HU15M3, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 9lbs

Want it shipped today?

  • Order within the next 9 hours and 3 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV71HU15M3 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Product Description

The ATV71HU15M3 is a Variable speed drive ATV71 - 1.5kW-2HP - 240V - E... that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the altivar-71 line come with a 2 year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
