BMXDAI1604

2-year Warranty

Same Day Shipping

Schneider Electric BMXDAI1604

M340 DIGITAL 16 INPUT I/O MODULE - 100 TO 120 VAC

5/5
1 rating

Select Condition

Refurbished

Request Quote

New

9 in stock

$879.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberBMXDAI1604
ManufacturerSchneider Electric
TypeI/O Modules
Model #BMX-DAI-1604
Warranty2 Year
RangeModicon X80
InputCapacitive
ComponentDiscrete input
Input no.16 Discrete input
Input compatibilityWith 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2
Discrete input100...120 V AC
Discrete input current5 mA
ProtectionIP20
CertificationsCE, CSA, UL, RCM, Merchant Navy, EAC
StandardsEN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201
Frequency50/60 Hz
Frequency range47...63 Hz
Sensor power supply20...26 V
Input impedance13000 Ohm
Insulation resistance> 10 MOhm 500 V DC
MTBF reliability1504958 H
Power dissipation <= 3.8 W
Current consumption90 mA at 3.3 V DC
Vibration resistance3 gn
Shock resistance 30 gn
Status LED1 LED red module error (ERR) 1 LED green module operating (RUN) 1 LED per channel green channel diagnostic 1 LED red module I/O
