BMXDDO6402K

2-year Warranty

Same Day Shipping

Schneider Electric BMXDDO6402K

MODICON X80 DISCRETE OUTPUT MODULE X80 - 64 OUTPUTS - SOLID STATE - 24 V DC POSITIVE

Select Condition

Refurbished

Request Quote

New

3 in stock

$879.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberBMXDDO6402K
ManufacturerSchneider Electric
TypeI/O Modules
Model #BMX-DDO-6402K
Warranty2 Year
RangeModicon X80
CategoryDiscrete output module
Description64 transistor output
Current per channel0.125 A
Discrete output typeSolid state
Discrete output current0.1 A
Discrete output number64 EN/IEC 61131-2
Discrete output voltage24 V 19...30 V DC
Discrete output logicPositive
Maximum current per module6.4 A
Power dissipation6.85 W
Response time on output1.2 ms
Typical current consumption160 mA 3.3 V DC
Switching frequency0.5/LI² Hz
Insulation resistance> 10 MOhm 500 V DC
MTBF reliability150000 H
Maximum overload time15 ms
Status LED1 LED (Green) +32 channels indicator 1 LED (Green) module operating (RUN) 1 LED per channel (Green) channel diagnostic 1 LED (Red) module error (ERR) 1 LED (Red) module I/O
Load impedance ohmic>= 220 Ohm
ProtectionIP20
Vibration resistance3 gn
Shock resistance30 gn
Ambient Air Temperature-40…185 °F (-40…85 °C)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed BMXDDO6402K to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this BMXDDO6402K we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty BMXDDO6402K, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 12 hours and 56 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty BMXDDO6402K for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric BMXDDO6402K Overview

BMXDDO6402K Discrete Output Module

Introduction:

The BMXDDO6402K is a cutting-edge discrete output module within the Modicon X80 range, designed to elevate the capabilities of industrial automation systems. This module boasts 64 transistor outputs, making it a powerhouse for applications demanding precision and reliability.

Unveiling the Specifications:

Category: Discrete Output Module

  • The BMXDDO6402K falls under the discrete output module category, catering to the specific needs of industrial processes that require precise control over outputs.

64 Transistor Outputs:

  • This module features an impressive 64-transistor output, providing an extensive range for managing various industrial tasks.

Current Per Channel: 0.125 A

  • Each channel is capable of handling a current of 0.125 A, ensuring optimal performance and flexibility in output control.

Solid State Technology:

  • Utilizing solid-state technology, the discrete outputs deliver reliability and longevity in demanding industrial environments.

Output Voltage: 24 V (19-30 V DC)

  • Operating within a voltage range of 19 to 30 V DC, the BMXDDO6402K ensures compatibility with diverse industrial setups.

Positive Logic:

  • The discrete outputs employ positive logic, enhancing the ease of integration and ensuring seamless communication within the automation system.

Maximum Current per Module: 6.4 A

  • With a maximum current handling capacity of 6.4 A per module, this discrete output module meets the demands of high-performance industrial applications.

Power Dissipation: 6.85 W

  • Efficient power dissipation at 6.85 W ensures that the module operates optimally while maintaining a balance between performance and energy efficiency.

Response Time: 1.2 ms

  • A rapid response time of 1.2 ms guarantees real-time control and execution of commands, contributing to the overall efficiency of industrial processes.

MTBF Reliability: 150,000 H

  • The Mean Time Between Failures (MTBF) reliability of 150,000 hours underscores the durability and robustness of the BMXDDO6402K in industrial settings.

Smart Features for Enhanced Monitoring:

  • LED Indicators:
    • The module is equipped with LED indicators, including a green module operating (RUN) LED, channel diagnostic LEDs, and red LEDs for module error (ERR) and module I/O. These indicators offer visual cues for quick diagnostics and status monitoring.

Endurance in Harsh Environments:

  • Protection and Resistance:
    • With an IP20 protection rating, the module is safeguarded against dust and solid objects. It also exhibits resilience to vibrations (3 gn) and shocks (30 gn), ensuring reliability in challenging industrial environments.

Temperature Tolerance:

  • Ambient Air Temperature Range: -40…185 °F (-40…85 °C)
    • Operating flawlessly across a wide temperature range, from -40 to 185 °F (-40 to 85 °C), the BMXDDO6402K thrives in diverse industrial climates.

Frequently Asked Questions

1. What is the primary application of the BMXDDO6402K discrete output module?

  • The BMXDDO6402K is designed for industrial automation systems, specifically for applications that require precise control over discrete outputs. Its 64 transistor outputs make it suitable for a wide range of industrial tasks.

2. How does the positive logic of the discrete outputs impact integration within an automation system?

  • Positive logic simplifies integration by ensuring a consistent and intuitive communication interface within the automation system. It enhances the ease of programming and coordination with other components.

3. Can the BMXDDO6402K handle high-current industrial applications?

  • Yes, the BMXDDO6402K is equipped to handle high-current applications with a maximum current capacity of 6.4 A per module, making it suitable for demanding industrial processes.

4. What is the significance of LED indicators on the module?

  • The LED indicators, including a green operating (RUN) LED, channel diagnostic LEDs, and red LEDs for module error (ERR) and module I/O, provide visual cues for quick diagnostics and status monitoring. They aid in identifying issues and ensuring smooth operation.

5. How does the module ensure reliability in challenging environments?

  • The BMXDDO6402K is designed with an IP20 protection rating, making it resistant to dust and solid objects. Additionally, it exhibits vibration resistance (3 gn) and shock resistance (30 gn), ensuring durability and reliability in harsh industrial environments.

6. What is the response time of the BMXDDO6402K?

  • The BMXDDO6402K boasts a rapid response time of 1.2 ms, ensuring real-time control and execution of commands. This quick response contributes to the overall efficiency of industrial processes.

7. Can the module operate in extreme temperature conditions?

  • Yes, the BMXDDO6402K is designed to operate across a wide temperature range, from -40 to 185 °F (-40 to 85 °C), making it suitable for deployment in diverse industrial climates.

8. Is the module compatible with other Modicon X80 components?

  • Yes, the BMXDDO6402K is part of the Modicon X80 range, ensuring compatibility with other components within the same series. Users should refer to product documentation for specific compatibility details.

9. How can I ensure optimal performance and longevity of the BMXDDO6402K?

  • To ensure optimal performance and longevity, it is recommended to adhere to the specified operating conditions, follow installation guidelines, and regularly monitor LED indicators for any diagnostic information.

10. Can the module be used in applications with varying load impedances?

  • Yes, the BMXDDO6402K is designed to accommodate a wide range of load impedances, with a minimum requirement of >= 220 Ohm.

In conclusion, the BMXDDO6402K discrete output module is a technological marvel within the Modicon X80 range, offering precision, reliability, and smart features that cater to the evolving needs of industrial automation. With its robust specifications and endurance in harsh environments, this module stands as a testament to innovation and excellence in the field of discrete output control.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.

Contact Us Today For More Information About Schneider Electric Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like BMXDDO6402K, take a look at more from our I/O Modules line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our BMXDDO6402K products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
