DIG 8Q RELAY 125 VDC 0.3A ROHS COMPLIANT
| Part Number | BMXDRA0804T |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | BMX-DRA-0804T |
| Warranty | 2 Year |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed BMXDRA0804T to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this BMXDRA0804T we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty BMXDRA0804T, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty BMXDRA0804T for credit when ordering from MRO Electric
The Schneider Electric BMXDRA0804T is a high-performance digital output relay module designed for use with Modicon M340 programmable logic controllers (PLCs). This module features eight discrete relay outputs intended to operate with a voltage of up to 125 VDC and a maximum current of 0.3 A per channel. Engineered for industrial environments, the BMXDRA0804T ensures reliable switching for a wide range of automation applications, including machinery control, process automation, and discrete manufacturing operations.
As part of Schneider Electric's trusted Modicon range, the BMXDRA0804T is built with precision and quality, offering seamless integration into existing Modicon M340 PLC architectures. It complies with RoHS standards, confirming its environmentally conscious design. Its form factor and robust design allow it to withstand harsh environments and fluctuating power conditions, making it an ideal solution for demanding automation tasks.
Unlike transistor-based outputs, this relay module offers electrically isolated switching, making it suitable for both AC and DC loads. With eight independent relay channels, it provides versatile output control for motors, actuators, solenoids, and other devices. The relay contacts provide a solid and dependable switching mechanism, reducing the risk of signal interference and providing electrical isolation between the load and the controller.
Designed for quick setup, the Schneider Electric BMXDRA0804T is user-friendly and includes standard terminal blocks for straightforward wiring. Diagnostic indicators on the module assist in easy troubleshooting and system monitoring. Its modular nature supports scalable system design, allowing users to add or replace modules with minimal downtime or reconfiguration.
The BMXDRA0804T is available immediately through MRO Electric and Supply and comes with a 2-year warranty for added assurance. Customers also benefit from free shipping, ensuring fast and cost-effective delivery. With MRO Electric's responsive customer service, technical support, and comprehensive product knowledge, you can be confident in every purchase and deployment.
What does the BMXDRA0804T module do?
It provides eight discrete relay outputs for controlling various electrical loads via a Modicon M340 PLC.
What type of loads can it switch?
It can switch both AC and DC loads, such as solenoids, relays, contactors, and lights.
What is the voltage rating per channel?
Each output can handle up to 125 VDC at a maximum of 0.3A.
Is it RoHS compliant?
Yes, the BMXDRA0804T meets RoHS compliance standards.
Can this module be used with the Modicon M340 PLC?
Yes, it is specifically designed for compatibility with the Modicon M340 series.
Does this module provide electrical isolation?
Yes, its relay outputs ensure electrical isolation between the PLC and external loads.
Is there a warranty with the purchase?
MRO Electric provides a 2-year warranty with every purchase.
Is this product available immediately?
Yes, MRO Electric stocks the module and offers same-day shipping.
Does it require any special tools for installation?
No, standard tools and wiring techniques are sufficient for installation.
Are technical resources or manuals available?
Yes, documentation is available through Schneider Electric and MRO Electric support.
