BMXXBP0600

2-year Warranty

Same Day Shipping

Schneider Electric BMXXBP0600

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Backplane - 6 Slots
PRODUCT TYPE INFO: M340


Available


Free Shipping

2 Year warranty

Part NumberBMXXBP0600
ManufacturerSchneider Electric
TypeBackplane Models
Model #BMX-XBP-0600
Warranty2 Year
RangeModicon M340 automation platform
CategoryRack
Slots6 bus X
Power rating1.5 W
ProtectionIP20
CompatibilityBMXP34 processor I/O module Specific application module BMXCPS power supply
Ambient air temp32…140 °F
Connection1 connector (XBE) expansion module
Relative humidity10…95 % without condensation
Net Weight1.74 lb
Protective treatmentTC
MountingPlate/DIN rail mounting

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed BMXXBP0600 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this BMXXBP0600 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty BMXXBP0600, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 15 hours and 44 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty BMXXBP0600 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric BMXXBP0600 Overview

Schneider Electric BMXXBP0600

The Modicon M340 automation platform is a versatile and robust system designed for industrial automation, and the BMXXBP0600 rack is a key accessory within this range. In this overview, we'll delve into the features and specifications of the BMXXBP0600 rack.

Modicon M340 Automation Platform: BMXXBP0600 Rack

Overview:

The BMXXBP0600 is a rack designed for the Modicon M340 automation platform, offering flexibility and scalability for a wide range of industrial applications. It serves as a housing unit for various modules, accommodating up to 6 bus X slots for components like BMXP34 processors, I/O modules, and specific application modules.

Key Features:

  • Number of Slots: The rack provides 6 bus X slots, allowing users to customize their automation setup based on the specific requirements of their processes.
  • Compatibility: The BMXXBP0600 rack is compatible with several Modicon M340 components, including BMXP34 processors, I/O modules, and specific application modules. This compatibility ensures seamless integration within the automation platform.
  • Power Consumption: With a power consumption of 1.5 W, the BMXXBP0600 rack is energy-efficient, contributing to overall system sustainability.
  • Electrical Connection: The rack features an electrical connection through a connector (XBE) expansion module, providing a reliable and secure interface for expansion modules.
  • Fixing Modes: The rack offers multiple fixing options, including 4 screws for panel mounting (0.17…0.25 in or 4.32…6.35 mm), 4 M6 screws for plate mounting, and clips for 35 mm symmetrical DIN rail mounting. These options provide installation flexibility based on user preferences and spatial constraints.
  • Weight and Dimensions: Weighing 1.74 lb (0.79 kg), the BMXXBP0600 rack is designed with a focus on lightweight construction without compromising durability. This makes it suitable for various industrial environments.

Environmental Specifications:

  • IP Degree of Protection: The rack has an IP20 degree of protection, safeguarding it from solid objects and providing protection against accidental contact.
  • Ambient Air Temperature: The BMXXBP0600 operates effectively in ambient air temperatures ranging from 32 to 140 °F (0 to 60 °C), making it suitable for diverse industrial settings.
  • Relative Humidity: With a relative humidity tolerance of 10 to 95% without condensation, the rack is adaptable to environments with varying humidity levels.
  • Protective Treatment: The BMXXBP0600 undergoes protective treatment with TC, enhancing its resilience against environmental factors.

Frequently Asked Questions

1. What is the BMXXBP0600 rack used for in the Modicon M340 automation platform?

  • The BMXXBP0600 rack is an essential component in the Modicon M340 automation platform, serving as a housing unit for various modules, including BMXP34 processors, I/O modules, and specific application modules.

2. How many slots does the BMXXBP0600 rack provide for modules?

  • The rack offers 6 bus X slots, allowing users to customize their automation setup by accommodating up to six different modules.

3. What components are compatible with the BMXXBP0600 rack?

  • The rack is compatible with BMXP34 processors, I/O modules, and specific application modules within the Modicon M340 automation platform, ensuring seamless integration.

4. What fixing options are available for the BMXXBP0600 rack?

  • The rack provides versatile fixing options, including 4 screws for panel mounting (0.17…0.25 in or 4.32…6.35 mm), 4 M6 screws for plate mounting, and clips for 35 mm symmetrical DIN rail mounting.

5. What is the power consumption of the BMXXBP0600 rack?

  • The rack has a power consumption of 1.5 W, contributing to energy efficiency within the overall automation system.

6. Where is the BMXXBP0600 rack manufactured?

  • The BMXXBP0600 rack is manufactured in France, ensuring compliance with high-quality standards associated with Modicon products.

7. What is the degree of protection for the BMXXBP0600 rack?

  • The rack has an IP20 degree of protection, providing protection against solid objects and preventing accidental contact.

8. Can the BMXXBP0600 rack be mounted on a DIN rail?

  • Yes, the rack can be mounted on a 35 mm symmetrical DIN rail using clips, offering a convenient and secure installation option.

9. What is the ambient temperature range for the BMXXBP0600 rack?

  • The rack operates effectively in ambient air temperatures ranging from 32 to 140 °F (0 to 60 °C), making it suitable for diverse industrial environments.

10. Does the BMXXBP0600 rack undergo any protective treatment?

  •  Yes, the rack undergoes protective treatment with TC, enhancing its resilience against environmental factors.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Backplane Models from other manufacturers such as Modicon and ABB.
