Schneider Electric BMXXBP1200

BACKPLANE MODELS BACKPLANE - 12 SLOTS

5/5
1 rating

Select Condition

Refurbished

Request Quote

New

3 in stock

$397.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberBMXXBP1200
ManufacturerSchneider Electric
TypeBackplane Models
Model #BMX-XBP-1200
Warranty2 Year
RangeModicon M340 automation platform
Category Rock
Slots12 bus X
CompatibilityI/O module BMXP34 processor Specific application module BMXCPS power supply
ProtectionIP20
Power consumption0.74 W
Ambient temp0…60 °C
Connection1 connector (XBE) expansion module
Protective treatmentTC
MountingBy 4 screws - diameter: 4.32…6.35 mm, mounting on panel By 4 M6 screws, mounting on plate
Relative humidity10…95 % without condensation

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed BMXXBP1200 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this BMXXBP1200 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty BMXXBP1200, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 7 hours and 53 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty BMXXBP1200 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric BMXXBP1200 Overview

Schneider Electric BMXXBP1200

The Schneider Electric BMXXBP1200 is an essential component within the main ring of a typical M580 system. As part of the Altivar 71 range, this local rack provides the critical components required for efficient motor control and communication in complex, high-power machines.

Key Components and Configuration:

The BMXXBP1200 local rack houses the CPU, a power supply, and up to six Ethernet communication modules. These modules may include up to three BMENOC0301/BMENOC0311 modules, BMENOS0300 network option switch modules, and up to two BMENOC0321 control network modules. This configuration allows for seamless communication between devices and efficient data exchange within the system.

Main and Extended Racks:

The local rack consists of a main rack and can accommodate up to seven full extended racks, which can contain up to 14 Premium half racks, depending on the specific CPU used. The main rack is a mandatory component in the M580 architecture, while the extended racks are optional but beneficial for expanding the system's capabilities. The main rack acts as the core unit and the extended racks are considered part of the local rack when added.

Module Compatibility:

The BMXXBP1200 local rack supports Modicon X80 I/O modules on either BMEXBP••00 Ethernet or BMXXBP0•00 X Bus backplanes. Additionally, it is compatible with Modicon eX80 modules, such as the PMESWT0100 and BMEAH•0•12 modules, which can be installed specifically on BMEXBP••00 Ethernet backplanes. For enhanced versatility, the BMEXBP1202 backplanes support both Ethernet and X Bus communications, allowing the installation of both Modicon eX80 and Modicon X80 modules.

Advanced Control and Energy Adaptation:

This local rack is equipped with an Energy Adaptation (ENA) system, which effectively handles unbalanced loads within the system. This feature ensures stable and consistent performance, even when dealing with dynamic and uneven load conditions. Additionally, the local rack supports Sensorless Flux Vector Control (SFVC), offering precise control over motor torque and speed without the need for external feedback sensors.

Integrated EMC Filter for Enhanced Performance:

The BMXXBP1200 local rack comes with an integrated Electromagnetic Compatibility (EMC) filter, which suppresses electromagnetic noise, maintaining smooth and reliable operation in environments with high electromagnetic interference. The integrated EMC filter ensures compliance with EMC standards, contributing to the system's overall robustness and efficiency.

Scalable and Expandable System:

The modular design of the BMXXBP1200 local rack allows for easy expansion and scalability. By adding extended racks, the system can accommodate more I/O modules, providing additional capabilities and enhancing system performance.

Schneider Electric BMXXBP1200 Backplane: Frequently Asked Questions (FAQ)

1. What is the Schneider Electric BMXXBP1200 Backplane used for?

The Schneider Electric BMXXBP1200 is a 12-slot backplane designed for the Modicon M340 automation platform. It serves as a foundational component for connecting various modules such as I/O modules, power supply units, processors, and application-specific modules in industrial automation systems. The backplane facilitates seamless communication and power distribution between these components.

2. How many slots does the BMXXBP1200 backplane have?

The BMXXBP1200 backplane has 12 bus slots, allowing it to accommodate a combination of I/O modules, processors, and other necessary components, making it highly scalable for medium to large automation setups.

3. What devices are compatible with the BMXXBP1200?

This backplane is compatible with Schneider Electric's BMXP34 processors, BMXCPS power supply modules, and I/O modules within the Modicon M340 platform. It also supports specific application modules, making it versatile for various automation requirements.

4. What are the power consumption specifications of the BMXXBP1200?

The BMXXBP1200 backplane has a low power consumption of 0.74 watts, ensuring energy efficiency while maintaining reliable performance in continuous operations.

5. What is the protection level of this backplane?

The Schneider Electric BMXXBP1200 has an IP20 protection rating, which means it is protected against solid objects larger than 12.5mm, such as fingers or tools. However, it is not resistant to water or dust, so it is best suited for clean, dry environments like control panels or automation cabinets.

6. What is the operating temperature range for the BMXXBP1200?

The BMXXBP1200 is designed to operate in ambient temperatures ranging from 0°C to 60°C (32°F to 140°F), making it suitable for a variety of industrial environments, including those with moderate temperature fluctuations.

7. How is the backplane mounted?

The BMXXBP1200 can be mounted in two ways:

Using four screws with a diameter of 4.32 to 6.35 mm for panel mounting.

By using four M6 screws for mounting on a plate. Both methods ensure secure and stable installation within the control cabinet or enclosure.

8. Does the BMXXBP1200 have any protective treatments?

Yes, the BMXXBP1200 is treated with protective coating TC, which helps safeguard the backplane from harsh environmental factors such as humidity, dust, and minor vibrations, ensuring long-term reliability in industrial settings.

9. What is the relative humidity tolerance of the BMXXBP1200?

This backplane can operate in environments with a relative humidity range of 10% to 95%, provided there is no condensation. This wide humidity range allows it to function reliably in both dry and humid conditions, making it suitable for various industrial applications.

10. Is there a warranty available for the BMXXBP1200 backplane?

Yes, when purchased from MRO Electric and Supply, the Schneider Electric BMXXBP1200 backplane comes with a 2-year warranty. This warranty ensures that any defects or malfunctions will be covered, providing peace of mind for users. MRO Electric also offers free shipping, further enhancing the value of the purchase.

11. What kind of connection does the backplane support for expansion?

The BMXXBP1200 supports a single connector for the XBE expansion module. This allows for easy extension of the system, offering flexibility for users who need to expand their automation setup over time.

12. What is the significance of the Modicon M340 platform for automation?

The Modicon M340 platform is known for its compact size, high performance, and robust reliability in industrial automation. It is widely used in various industries for controlling and managing complex processes, making it an integral part of scalable, modular automation solutions. The BMXXBP1200 backplane is a key component that helps to build and extend this platform's capabilities.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Backplane Models from other manufacturers such as Modicon and ABB.
