SP4403

SP4403

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Control Techniques

DESCRIPTION: 400V AC Panel Mount Drive SP4403

PRODUCT TYPE INFO: Unidrive SP

1 in stock
Ships Today

2 Year warranty
Part NumberSP4403
ManufacturerControl Techniques
Model #SP4403
TypeAC Drives
Warranty2 Year
Typical Motor Output Power (HP)60
Input Voltage380 - 480VAC
Frame Size4
Normal Duty
Max Cont. Current (A)104
Typical Motor Output Power (kW)55
Typical Motor Output Power (HP)75
Heavy Duty
Max Cont. Current (A)96
Typical Motor Output Power (kW)45

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed SP4403 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this SP4403 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty SP4403, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 72lbs

Want it shipped today?

  • Order within the next 15 hours and 30 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty SP4403 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Control Techniques SP4403 Overview

The SP4403 400 V, the dual-rated drive is manufactured by Control Techniques for the UNIdrive line of AC drives. For normal duty, the application must use self-ventilated induction motors, must be capable of low overload, and should not require full torque when used at low speeds. For heavy-duty, the application needs constant torque or need to be capable of high overload, need full torque at low speeds. In heavy-duty, which is the default, the thermal protection is set to protect both the induction motors and the servo motors.

Features

The Control Techniques SP4403 400 V (380V to 480V ±10%) drive module has a normal duty max continuous output of 104 A. The normal duty nominal power at 400 V is 55 kW.  The normal duty motor power rating at 460 V is 75 hp. The normal duty peak current for the SP4403 is 114 A.

For heavy-duty, the Unidrive maximum continuous output current is 96 A. The open-loop peak current in heavy-duty is 114 A, and the closed-loop peak current in heavy-duty is 168 A. The nominal power at 400 V is 45 kW and the motor power at 460 V is 75 hp in heavy-duty mode.

On the top left front of the Control Techniques SP4403 is the AC supply connection. Next to the AC supply connection, to the right, are the DC supply connections. The internal EMC filter is under the AC supply connection. The front bottom features of the Unidrive SP4403 are the motor connectors and the brake resistor. They are on the left front and middle respectively, followed by the low voltage DC mode enable area which is located on the front bottom right.

Advantages

The Control Techniques SP4403 utilizes option modules for optimum performance. The option modules available for the SP4403 Unidrive include several color-coded solution modules. There are five feedback option modules, seven automation I/O expansion modules, 5 application modules for automation, and nine Fieldbus solutions modules.  The SP4430 also has keypad options.

How to use an SP4430

The Control Techniques SP4430 is engineered for installation in an enclosure.  A couple of mounting options include IP54 as standard or through-panel mounting. Features to consider when installing are the enclosure sizing and layout, the option solutions module fitting and how that will fit into the enclosure, the torque settings, and finally the location of the terminal. The IP rating of the Sp4430 depends on the installation of the drive.

There are protections to consider for installation including moisture levels in the drive installation area. This includes spraying and dripping water as well as condensation. Another consideration is contamination with materials that are electrically conductive or dusty areas that could tamper with the fan’s ability to cool. It should not be installed in areas that could potentially have prohibitive airflow or exposure to corrosive gasses. The Control Techniques drive should be used and stored in ranges specified in the user manual.

The Control Techniques dual rated, 400 V Unidrive module SP4403 comes with a two-year warranty.

Product Description

The SP4403 is a 400V AC Panel Mount Drive SP4403 that is manufactured by Control Techniques. These products are manufactured in United Kingdom and are designed for Metal production, paper processing, and material conveying usage. All of the products come with a 2 year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Siemens and Yaskawa.
