MANUFACTURER: Schneider Electric
DESCRIPTION: Discrete Output Module - 8 Relay Protected Output - 24..240V AC - 5 A
PRODUCT TYPE INFO: Modicon Micro
Available
Free Shipping
2 Year warranty
| Part Number | TSXDSY08R5AC |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | TSX-DSY-08R5AC |
| Warranty | 2 Year |
| Product weight | 0.37 kg |
| Range of product | Modicon Premium Automation platform |
| Product or component type | Discrete output module |
| Discrete output number | 8 |
| Discrete output type | Relay protected |
| Discrete output voltage | 24...240 V AC conforming to EN/IEC 61131-2 20...264 V |
| 24...48 V DC conforming to EN/IEC 61131-2 19...60 V | |
| [Ith] conventional free air thermal | 5 A |
| Response time | < 10 ms activation |
| < 15 ms deactivation | |
| Contacts type and composition | 2 x 2 C/O + 2 x 2 NO |
| Output overvoltage protection | RC circuit and Ge-Mov |
| Output overload protection | 6.3 A, interchangeable fuse per common fast blow |
| Short-circuit protection | 6.3 A, interchangeable fuse per common fast blow |
| Insulation resistance | > 10 MOhm 500 V |
| Power dissipation | (0.25 W + 0.24 W x No of outputs at state 1) |
| Electrical durability | 1000000 cycles DC-12 24 W 24 V resistive |
| 1000000 cycles DC-12 50 W 48 V resistive | |
| 1000000 cycles DC-3 24 W 24 V inductive | |
| 1000000 cycles DC-3 50 W 48 V inductive | |
| 2000000 cycles DC-3 10 W 24 V inductive | |
| 2000000 cycles DC-3 24 W 48 V inductive | |
| 300000 cycles DC-12 100 W 48 V resistive | |
| 300000 cycles DC-12 50 W 24 V resistive | |
| 1000000 cycles AC-12 100 VA 48 V resistive | |
| 2000000 cycles AC-14 50 VA 48 V inductive | |
| 2000000 cycles AC-15 50 VA 48 V inductive | |
| 500000 cycles AC-12 200 VA 48 V resistive | |
| 500000 cycles AC-14 50 VA 24 V inductive | |
| 500000 cycles AC-15 50 VA 24 V inductive | |
| 5000000 cycles AC-14 20 VA 48 V inductive | |
| 5000000 cycles AC-15 20 VA 48 V inductive | |
| 700000 cycles AC-12 100 VA 24 V resistive | |
| 100000 cycles AC-14 440 VA 220...240 V inductive | |
| 100000 cycles AC-15 440 VA 220...240 V inductive |
| 1000000 cycles AC-12 220 VA 100...120 V resistive | |
| 1000000 cycles AC-12 440 VA 220...240 V resistive | |
| 1000000 cycles AC-14 220 VA 220...240 V inductive | |
| 1000000 cycles AC-15 220 VA 220...240 V inductive | |
| 10000000 cycles AC-14 20 VA 100...120 V inductive | |
| 10000000 cycles AC-14 20 VA 220...240 V inductive | |
| 10000000 cycles AC-15 20 VA 100...120 V inductive | |
| 10000000 cycles AC-15 20 VA 220...240 V inductive | |
| 150000 cycles AC-14 220 VA 100...120 V inductive | |
| 150000 cycles AC-15 220 VA 100...120 V inductive | |
| 1500000 cycles AC-14 110 VA 100...120 V inductive | |
| 1500000 cycles AC-15 110 VA 100...120 V inductive | |
| 3000000 cycles AC-14 110 VA 220...240 V inductive | |
| 3000000 cycles AC-15 110 VA 220...240 V inductive | |
| 500000 cycles AC-12 440 VA 100...120 V resistive | |
| Marking | CE |
| Electrical connection | Screw terminal block |
| Current consumption | 55 mA 5 V DC |
| 80 mA 24 V DC rack | |
| Module format | Standard |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TSXDSY08R5AC to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TSXDSY08R5AC we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TSXDSY08R5AC, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty TSXDSY08R5AC for credit when ordering from MRO Electric
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like TSXDSY08R5AC, take a look at more from our I/O Modules line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our TSXDSY08R5AC products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
