TSXDSY16T2

2-year Warranty

Same Day Shipping

Schneider Electric TSXDSY16T2

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Schneider Electric

DESCRIPTION: Discrete Output Module - 16 O Solid State

PRODUCT TYPE INFO: Modicon Premium

12 in stock


Free Shipping

2 Year warranty

Part NumberTSXDSY16T2
ManufacturerSchneider Electric
TypeI/O Modules
Model #TSX-DSY-16T2
Warranty2 Year
Module formatStandard
Product or component typeDiscrete output module
Discrete output number16
Discrete output typeSolid state protected
Discrete output voltage24 V DC positive conforming to EN/IEC 61131-219...30 V
Discrete output current0.5 A
Current per channel<= 0.625 A
Current per module<= 7 A
Leakage current< 0.5 mA at state 0
[Ures] residual voltage< 1.2 V
Response time1.2 ms
Switching frequency0.5/LI² Hz
Output overvoltage protectionBy transil diode
Reverse polarity protectionReverse mounted diode
Output overload protectionElectronic tripping on reactivation
Short-circuit protectionElectronic tripping on reactivation
Preactuator voltage detection threshold16 V
Load impedance>= 48 W
Isalotion resistance> 10 MOhm 500 V
Power dissipation(1.1 W + 0.75 W x No of outputs x current per module)
MarkingCE
Electrical connectionScrew terminal block
Current consumption80 mA 5 V DC

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXDSY16T2 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXDSY16T2 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXDSY16T2, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 21 hours and 37 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXDSY16T2 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXDSY16T2 Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.

Schneider Electric TSXDSY16T2 Discrete Output Module: Reliable and Efficient I/O Solution

In industrial automation and control systems, the Schneider Electric TSXDSY16T2 stands out as a robust and versatile discrete output module. Manufactured by Schneider Electric, a leading name in the field, this module exemplifies innovation, durability, and performance. Designed to facilitate seamless integration into various applications, the TSXDSY16T2 offers a comprehensive array of features that make it an indispensable component in modern industrial setups.

Unveiling the TSXDSY16T2:

At its core, the TSXDSY16T2 is an I/O module, a fundamental building block of automation systems. Its model number, TSX-DSY-16T2, indicates its specific configuration. One of the standout features of this module is its discrete output capability. With 16 discrete outputs, this module enables precise control and manipulation of connected devices. The outputs are of the solid-state protected type, ensuring reliability and enhanced protection against various electrical anomalies.

Performance Parameters:

The module operates within a voltage range of 24 V DC to 30 V DC, conforming to the EN/IEC 61131-2 standard. Each discrete output can handle a current of up to 0.5 A, with a current per channel limited to 0.625 A. This prudent current distribution ensures optimal performance and longevity of the module. In terms of response time, the TSXDSY16T2 boasts an impressive 1.2 ms, ensuring swift and accurate execution of control commands.

For enhanced protection and longevity, the module incorporates various safety features. Output overvoltage protection is facilitated by a transil diode, preventing voltage spikes from harming the module or connected devices. Reverse polarity protection, through a reverse-mounted diode, safeguards against incorrect wiring. The module also features short-circuit and output overload protection, employing electronic tripping mechanisms upon reactivation to prevent damage.

Efficiency and Reliability:

Energy efficiency is a critical concern in modern industrial setups. The TSXDSY16T2 addresses this by offering a low leakage current of less than 0.5 mA at state 0, minimizing wastage. The residual voltage, denoted by [Ures], is impressively low, measuring less than 1.2 V. This ensures that connected devices receive the intended voltage without unnecessary loss.

The module's isolation resistance of over 10 MOhm at 500 V guarantees proper electrical separation, contributing to the safety and stability of the entire system. Furthermore, the preactuator voltage detection threshold of 16 V enhances compatibility with various devices.

Installation and Integration:

The TSXDSY16T2 is designed with ease of use in mind. It features a screw terminal block for electrical connections, simplifying the installation process. The module's compact design and standard module format make it versatile and easy to incorporate into different setups.

Conclusion:

In conclusion, the Schneider Electric TSXDSY16T2 discrete output module embodies the principles of efficiency, reliability, and innovation. With its 16 solid-state protected discrete outputs, impressive performance parameters, and comprehensive safety features, it serves as a cornerstone for industrial automation and control systems. The module's adherence to industry standards, low energy consumption, and meticulous design all contribute to its status as a trusted solution for discrete output control. Whether in manufacturing, process control, or any other industrial application, the TSXDSY16T2 continues to demonstrate Schneider Electric's commitment to excellence and advancement in the world of automation. Backed by a 2-year warranty and marked with the CE label, it exemplifies the blend of cutting-edge technology and industrial prowess that Schneider Electric is renowned for.
