TSXDSZ08R5

2-year Warranty

Same Day Shipping

Schneider Electric TSXDSZ08R5

MODICON MICRO TSX MICRO - 8 OUTPUT RELAY

5/5
1 rating

10 in stock


Free Shipping

2 Year warranty

Part NumberTSXDSZ08R5
ManufacturerSchneider Electric
TypeI/O Modules
Model #TSX-DSZ-08R5
Warranty2 Year
Range of productModicon TSX Micro automation platform
Product or component typeRelay discrete output module
Discrete output number8 screw terminal block
Contacts type and compositionNO
Output voltage limits19...264 V AC
10...34 V DC
[Ith] conventional free air thermal3 A
current
Power consumption in VA50 VA 24 V AC-12 resistive
110 VA 48 V AC-12 resistive
220 VA 110 V AC-12 resistive
220 VA 220 V AC-12 resistive
24 VA 24 V AC-15 inductive
24 VA 48 V AC-15 inductive
220 VA 220 V AC-15 inductive
110 VA 110 V AC-15 inductive
Power consumption in W24 V DC-12 resistive
24 V DC-13 inductive
Response time< 10 ms
Current consumption85 mA
Power dissipation in W1.5 W
Isolation voltage1500 V 1 s
Insulation resistance>= 10 mOhm
Sustainable offer statusNot Green Premium product
RoHS (date code: YYWW)Will not be compliant

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXDSZ08R5 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXDSZ08R5 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXDSZ08R5, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 26 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXDSZ08R5 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXDSZ08R5 Overview

Schneider Electric TSX-DSZ-08R5 Relay Discrete Output Module: Reliable, High-Performance Solution for Discrete Control

The Schneider Electric TSX-DSZ-08R5 is a relay discrete output module designed for the Modicon TSX Micro automation platform. It delivers reliable and precise output control in a compact package. This I/O module is part of Schneider Electric's Modicon range, a line recognized for its durability and high-performance standards in industrial automation applications. With eight relay discrete outputs, the TSX-DSZ-08R5 is equipped to handle a variety of automation tasks that require robust relay control, making it suitable for diverse applications in manufacturing, process control, and other industrial environments.

Robust Output Capabilities for Versatile Applications

The TSX-DSZ-08R5 features eight discrete relay outputs with normally open (NO) contacts, providing dependable control across multiple devices. The module's output voltage range spans 19-264V AC and 10-34V DC, enabling compatibility with both AC and DC circuits, thus offering flexibility to users needing mixed voltage output control. This versatility in voltage handling makes it well-suited for applications such as motor control, actuator operation, and other automated tasks requiring high-reliability relay switching.

High Current Handling and Thermal Performance

Each output on the TSX-DSZ-08R5 can handle a conventional free-air thermal current of up to 3A, allowing it to accommodate devices with moderate current requirements while maintaining safe and efficient operation. The relay output module is designed to withstand continuous use with excellent thermal dissipation properties, ensuring it can operate reliably in various industrial environments without overheating. The module's isolation voltage of 1500V and insulation resistance of ≥ 10 MΩ further enhance safety by providing adequate protection against short circuits and ensuring electrical isolation between outputs.

Optimized for Efficient Power Consumption

The TSX-DSZ-08R5 is optimized for energy efficiency, consuming 50 VA at 24V AC (resistive load) and up to 220 VA at 220V AC (resistive load). The module manages power consumption across different voltages efficiently for inductive loads, making it cost-effective and sustainable for energy-conscious operations. The TSX-DSZ-08R5 also consumes only 85mA of current, ensuring minimal impact on power supply demands in larger systems. Its low power dissipation of 1.5W reduces excess heat generation, improving the lifespan of both the module and the surrounding components.

Fast and Reliable Response Times

Designed to support rapid operations, the TSX-DSZ-08R5 offers a quick response time of less than 10 milliseconds. This responsiveness is essential for real-time control and feedback applications, such as monitoring and managing automated production lines. The TSX-DSZ-08R5's speed and accuracy enhance system performance by reducing latency, which is beneficial in high-demand environments where efficiency and precision are critical.

Durable Design with Enhanced Protection

Encased in robust housing with an IP20 protection rating, the TSX-DSZ-08R5 is built to withstand regular industrial wear and tear. The IP20 rating ensures adequate protection against dust and debris, making it suitable for installation in clean control cabinets or other indoor environments. Schneider Electric's commitment to durability is further emphasized by the module's two-year warranty from MRO Electric and Supply, providing users with additional assurance of the product's longevity.

FAQs for Schneider Electric TSX-DSZ-08R5 Relay Discrete Output Module

Q: What types of applications is the TSX-DSZ-08R5 module best suited for?

A: The TSX-DSZ-08R5 is ideal for applications requiring precise relay control, such as motor switching, actuator operation, and other automated functions requiring reliable, discrete output. Its versatility in AC and DC output control makes it suitable for various industrial automation environments.

Q: Can this module handle both AC and DC outputs?

A: The TSX-DSZ-08R5 is designed to manage outputs across a voltage range of 19-264V AC and 10-34V DC, allowing for mixed voltage control in a single module.

Q: How many discrete outputs are included, and what is their configuration?

A: The module includes eight discrete relay outputs with normally open (NO) contacts, providing robust and straightforward control for multiple devices.

Q: What is the maximum current each output can handle?

A: Each output can handle up to 3A of conventional free-air thermal current, making it suitable for moderate power applications.

Q: Does the TSX-DSZ-08R5 have built-in protection features?

A: It features an isolation voltage of 1500V and insulation resistance of ≥ 10 MΩ to ensure safety during operation and prevent damage from electrical faults.

Q: What is the module's response time?

A: The TSX-DSZ-08R5's response time is less than 10 milliseconds, allowing for fast and precise control, ideal for time-sensitive automation tasks.
