ADVANCED TOUCHSCREEN PANEL - 800 X 600 PIXELS SVGA - 12.1 - 24 V
Available
Free Shipping
2 Year MRO warranty
| Part Number | XBTGT6340 |
| Manufacturer | Schneider Electric |
| Type | HMIs |
| MRO Warranty | 2 Year |
| Product weight | 2.5 kg |
| Range of product | Magelis XBTGT |
| Product or component type | Advanced touchscreen panel |
| Display type | Backlit colour TFT LCD |
| Display colour | 65536 colours |
| Display resolution | 800 x 600 pixels SVGA |
| Display size | 12.1 inch |
| Software type | Configuration software |
| Software designation | Vijeo Designer |
| Operating system | Magelis |
| Processor name | CPU RISC |
| Processor frequency | 266 MHz |
| Memory description | Back up of data SRAM 512 kB lithium battery |
| Integrated connection type | COM2 serial link RJ45 RS485 <= 187.5 kbit/s Siemens MPI (187.5 kbits/s) |
| Resistance to electrostatic discharge | 6 kV IEC 61000-4-2 level 3 |
| Cut-out dimensions | 301.5 (+ 1/- 0) x 227.5 (+ 1/- 0) mm |
| Touch sensitive zone | 1024 x 1024 |
| Touch panel | Analogue |
| Brightness | 8 levels via touch panel |
| Character font | ASCII (European characters) |
| Japanese (ANK, Kanji) | |
| Korean | |
| Taiwanese (traditional Chinese) | |
| Chinese (simplified Chinese) | |
| [Us] rated supply voltage | 24 V DC |
| Supply | External source |
| Supply voltage limits | 19.2...28.8 V |
| Inrush current | <= 30 A |
| Power consumption | 30 W |
| Local signalling | 1 LED (green or orange) for normal operation or backlighting faulty |
| Number of pages | Limited by internal memory capacity |
| Downloadable protocols | FIPWAY Telemecanique Modicon |
| Modbus Plus Telemecanique Modicon | |
| Modbus TCP Telemecanique Modicon |
| Modbus Telemecanique Modicon | |
| Third party protocols Mitsubishi Melsec | |
| Third party protocols Omron Sysmac | |
| Third party protocols Rockwell Automation Allen-Bradley | |
| Third party protocols Siemens Simatic | |
| Uni-TE Telemecanique Modicon | |
| Realtime clock | Built-in |
| Memory type | 1 slot for Compact Flash card (128 MB to 1 GB) |
| Use of slot | For 1 fieldbus communication card (Device Net, Profibus DP) |
| Port Ethernet | 10BASE-T/100BASE-TX |
| Product mounting | Flush mounting |
| Fixing mode | By 4 spring clips |
| By 4 screw clamps | |
| Enclosure material | PPT |
| Marking | CE |
| Width | 313 mm |
| Height | 239 mm |
| Depth | 56 mm |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed XBTGT6340 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year MRO warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this XBTGT6340 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty XBTGT6340, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty XBTGT6340 for credit when ordering from MRO Electric
What is the replacement part number for a XBTZG46 backlight bulb?
The Schneider Electric XBTGT6340 is a powerful industrial touchscreen operator panel from the Magelis XBTGT series. Designed to provide precise visualization, reliable control, and intuitive operation, this HMI has been widely used across industrial automation systems. Although now discontinued by the manufacturer, it remains a sought-after solution for facilities that rely on its proven durability and performance.
Equipped with a 12.1-inch backlit color TFT LCD, the XBTGT6340 delivers excellent clarity for operators. With an 800 x 600 SVGA resolution, it ensures sharp visuals for process monitoring, making it ideal for control applications that demand accuracy and readability.
The HMI features a 266 MHz RISC CPU, providing responsive performance for operator interface functions. It's 32 MB Flash EPROM memory supports complex application data, while the 512 KB SRAM backup ensures data retention during power interruptions. This combination guarantees consistent and efficient operation in demanding environments.
The Magelis XBTGT6340 offers a fully touch-enabled interface, making it user-friendly for operators. Instead of relying on mechanical buttons, the touchscreen simplifies navigation, speeds up workflow, and enhances system interaction.
Built to Schneider Electric's high standards, the XBTGT6340 is engineered for continuous operation in harsh industrial environments. With a 24 VDC power supply (1.30 A), it provides stable performance and reliable functionality across a wide range of automation applications.
The Schneider Electric XBTGT6340 has been successfully deployed across industries, including:
Even though this model is discontinued, MRO Electric and Supply offers the Schneider Electric XBTGT6340 with a 2-year MRO warranty and free immediate shipping. This ensures that operators and facilities can continue to support their systems with a reliable replacement HMI.
What is the screen size of the XBTGT6340?
It has a 12.1-inch TFT LCD color touchscreen.
What is the display resolution?
The screen provides 800 x 600 pixels (SVGA resolution).
What type of processor is inside?
It uses a 266 MHz RISC CPU for fast and stable performance.
How much memory does it have?
The unit includes 32 MB Flash EPROM and 512 KB SRAM backup.
Is this model still manufactured?
No, the XBTGT6340 is no longer available from Schneider Electric, but it is still available from select suppliers.
What power supply does it require?
It operates on 24 VDC, 1.30 A.
What industries use this HMI?
It is commonly used in factory automation, packaging, process control, and OEM machinery.
Is it touch-enabled?
Yes, it features a complete touchscreen interface for easy operation.
What makes this HMI reliable?
Its industrial-grade durability and backup memory make it dependable for critical automation tasks.
Does MRO Electric provide warranty coverage?
Yes, every unit comes with a 2-year MRO warranty and free shipping.Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year MRO warranty from MRO Electric. We also carry HMIs from other manufacturers such as Modicon and ABB.
