XBTGT6330

2-year Warranty

Same Day Shipping

Schneider Electric XBTGT6330

MODICON MAGELIS ADVANCED TOUCHSCREEN PANEL - 800 X 600 PIXELS SVGA - 12.1 INCH TOUCHSCREEN -COLOR- TFT LCD - 24 V DC, OPERATOR INTERFACE, 1.3 AMP





5/5
2 ratings

Select Condition

Refurbished

2 in stock

New

1 in stock

$2,791.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberXBTGT6330
ManufacturerSchneider Electric
TypeHMIs
Warranty2 Year
Product weight2.5 kg
Range of productMagelis XBTGT
Product or component typeAdvanced touchscreen panel
Display typeBacklit colour TFT LCD
Display colour65536 colours
Display resolution800 x 600 pixels SVGA
Display size12.1 inch
Software typeConfiguration software
Software designationVijeo Designer
Operating systemMagelis
Processor nameCPU RISC
Processor frequency266 MHz
Memory descriptionBack up of data SRAM 512 kB lithium battery
Integrated connection typeCOM2 serial link RJ45 RS485 <= 187.5 kbit/s Siemens MPI (187.5 kbits/s)
Resistance to electrostatic discharge6 kV IEC 61000-4-2 level 3
Cut-out dimensions301.5 (+ 1/- 0) x 227.5 (+ 1/- 0) mm
Touch sensitive zone1024 x 1024
Touch panelAnalogue
Brightness8 levels via touch panel
Character fontASCII (European characters)
Chinese (simplified Chinese)
Japanese (ANK, Kanji)
Korean
Taiwanese (traditional Chinese)
[Us] rated supply voltage24 V DC
SupplyExternal source
Supply voltage limits19.2...28.8 V
Inrush current<= 30 A
Power consumption30 W
Local signalling1 LED (green or orange) for normal operation or backlighting faulty
Number of pagesLimited by internal memory capacity
Downloadable protocolsModbus Telemecanique Modicon
FIPWAY Telemecanique Modicon
Modbus Plus Telemecanique Modicon
Modbus TCP Telemecanique Modicon
Third party protocols Mitsubishi Melsec
Third party protocols Omron Sysmac
Third party protocols Siemens Simatic
Uni-TE Telemecanique Modicon
Third party protocols Rockwell Automation Allen-Bradley
Realtime clockBuilt-in
Memory type1 slot for Compact Flash card (128 MB to 1 GB)
Use of slotFor 1 fieldbus communication card (Device Net, Profibus DP)
Port Ethernet10BASE-T/100BASE-TX
Product mountingFlush mounting
Fixing modeBy 4 screw clamps
By 4 spring clips
Enclosure materialPPT
MarkingCE
Width313 mm
Height239 mm
Depth56 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed XBTGT6330 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this XBTGT6330 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty XBTGT6330, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 8lbs

Want it shipped today?

  • Order within the next 1 hour and 20 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty XBTGT6330 for credit when ordering from MRO Electric

What is the part number for the backlight on a XBTGT6330?

  • The backlight part number is XBTZG46.

What is the replacement of the Magelis XBTGT6330?

  • The direct replacement for the Magelis XBTGT6330 is the Magelis HMIGTO6310. The HMIGTO6310 12.1" touchscreen HMI can be mounted directly where the XBTGT6330 used to be located, as both are the same size.

What are the differences between the Magelis XBTGT6330 and the Magelis HMIGTO6310?

  • Unlike the Magelis XBTGT6330,connection to tohe Profibus DP, DeviceNet and CanOpen fieldbuses is not possible is not possible with the Magelis HMIGTO6310. Only RS232 serial link is possible with COM1. Use COM2 with RJ45 connector for RS485 serial. There is also no alarm output or loudspeaker output. Finally, SD Cards should be used instead of CF Cards for data logging, alarm history, etc storage. (capacity up to 32Gb)

Are there any other replacement options for the Magelis XBTGT6330?

  • There are no other direct replacement options for the Magelis XBTGT6330, however, there are several other options for the Magelis HMIGTO6310. If you’re looking for a replacement that has a higher IP rating, the HMIGTO6315 is near identical to the HMIGTO6310, except with a stainless steel bezel for IP67K protection. If you need a display with an alarm buzzer/speaker output, consider a combination of one of three types of HMIGTU (CPU back module) + HMIDT642 (12.1" touchscreen which snaps on to the HMIGTU). Examples of this include: HMIG2U + HMIDT642 HMIG3U + HMIDT642 Keep in mind any additional compatibility issues that might arise when combining these products.

What materials are used for the Magelis XBTGT6330/GT6340 housing?

  • The following are the materials used in the Magelis XBTGT6330/GT6340’s housing: Part Name Material Flame Resistance Rear Cover PC/PBT UL94 V-0 Front Sheet PET UL94 VTM-2 Front Bezel ADC12
MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric XBTGT6330 Overview

Schneider Electric XBTGT6330 HMI: Advanced Touchscreen Panel for Industrial Applications

The Schneider Electric XBTGT6330 is an advanced Human-Machine Interface (HMI) designed to enhance automation and process control in industrial environments. As part of the Magelis XBTGT range, this touchscreen panel offers a robust combination of high performance, intuitive user interaction, and adaptability for diverse industrial applications. The XBTGT6330 integrates cutting-edge technologies, including advanced communication protocols and real-time monitoring, ensuring seamless operation in demanding settings.

High-Performance Display

At the heart of the XBTGT6330 is a vibrant 12.1-inch backlit color TFT LCD supporting 65,536 colors. This high-resolution SVGA display (800 x 600 pixels) ensures clarity and precision, making it suitable for monitoring complex data and processes. The panel's brightness, adjustable across eight levels via the touch panel, enables optimal visibility in various lighting conditions. The XBTGT6330's wide touch-sensitive zone (1024 x 1024) also ensures precise input and enhances the user experience, allowing for efficient operation in fast-paced environments.

Intuitive User Interface and Customization

The XBTGT6330 comes equipped with Schneider Electric's Vijeo Designer software, a powerful tool that allows users to configure the HMI to meet specific operational needs. The panel supports multiple character fonts, including ASCII, simplified and traditional Chinese, Japanese, Korean, and Taiwanese, which makes it ideal for global industries. The touchscreen utilizes analog technology, ensuring accurate response to touch inputs and promoting efficient control.

Reliable Performance and Memory Capacity

Powered by a 266 MHz CPU RISC processor, the XBTGT6330 offers robust and reliable performance for industrial automation tasks. Its built-in SRAM memory (512 kB, backed by a lithium battery) ensures data integrity. At the same time, the HMI's compact flash card slot supports storage capacities ranging from 128 MB to 1 GB, providing ample room for storing configuration data, protocols, and system logs. Additionally, the XBTGT6330 features a built-in real-time clock, making it easier to monitor and record time-sensitive operations.

Versatile Connectivity and Protocol Support

The XBTGT6330 has versatile communication interfaces that ensure seamless integration with various automation systems. It features an Ethernet port (10BASE-T/100BASE-TX) for network connectivity and a COM2 serial link (RJ45 RS485) with a Siemens MPI communication capability of up to 187.5 kbit/s. The HMI supports a wide range of communication protocols, including Modbus, Modbus TCP, and Modbus Plus (Telemecanique Modicon), as well as third-party protocols from Mitsubishi Melsec, Siemens Simatic, Omron Sysmac, and Rockwell Automation Allen-Bradley. This extensive protocol support makes the XBTGT6330 highly adaptable to diverse industrial networks and control systems.

Robust Design and Safety Features

The XBTGT6330 is built to withstand the rigors of industrial environments. It boasts resistance to electrostatic discharge (6 kV, compliant with IEC 61000-4-2 level 3), ensuring reliable operation even in harsh conditions. The unit operates on a 24 V DC external power source, with a supply voltage range of 19.2 to 28.8 V, and has a power consumption of just 30 W, making it energy-efficient. The HMI also has a local signaling LED (green or orange) indicating normal operation or backlighting faults, providing real-time status feedback.

Flexible Mounting and Installation

The XBTGT6330 is designed for easy and secure installation through flush mounting. The unit can be fixed using either four screw clamps or four spring clips, ensuring stability in various industrial setups. Its compact dimensions (313 mm wide, 239 mm high, and 56 mm deep) allow for seamless integration into control panels, while its durable PPT enclosure material ensures long-lasting durability. The panel’s compliance with CE marking standards further guarantees its reliability and safety in industrial applications.

Warranty and Shipping

The Schneider Electric XBTGT6330 comes with a two-year MRO Electric and Supply warranty, providing peace of mind for industrial users. Additionally, MRO Electric offers free shipping, ensuring the product can be delivered efficiently and without added cost. Weighing just 2.5 kg, the HMI is lightweight and easy to handle during installation.

FAQs for Schneider Electric XBTGT6330 HMI

What type of display does the XBTGT6330 HMI feature?

The XBTGT6330 features a 12.1-inch backlit color TFT LCD with a resolution of 800 x 600 pixels (SVGA). It supports up to 65,536 colors, ensuring clear and vibrant visuals for monitoring and control applications. The brightness is adjustable across eight levels via the touch panel, offering flexibility for various lighting conditions.

What operating system and software are used with the XBTGT6330?

The XBTGT6330 operates on the Magelis operating system and is compatible with Schneider Electric’s Vijeo Designer software. Vijeo Designer allows users to configure and customize the HMI to meet specific needs, making it adaptable to various industrial applications.

What communication protocols are supported by the XBTGT6330?

The XBTGT6330 supports a wide range of communication protocols, including:

  • Modbus, Modbus TCP, and Modbus Plus (Telemecanique Modicon)
  • FIPWAY (Telemecanique Modicon)
  • Third-party protocols include Mitsubishi Melsec, Siemens Simatic, Omron Sysmac, and Rockwell Automation Allen-Bradley.

This flexibility enables the HMI to integrate with diverse industrial control systems and automation networks.

What are the power requirements for the XBTGT6330?

The XBTGT6330 operates on a 24 V DC external power source, with acceptable voltage limits ranging from 19.2 V to 28.8 V. Its maximum power consumption is 30 W, making it energy-efficient for industrial use.

How does the XBTGT6330 handle data storage and backup?

The HMI is equipped with 512 kB of SRAM for data backup, supported by a lithium battery. Additionally, the unit has one slot for a Compact Flash card with capacities ranging from 128 MB to 1 GB, allowing ample storage for configuration files, logs, and system data.

What are the dimensions and mounting options for the XBTGT6330?

The XBTGT6330 is designed for flush mounting and can be installed using either four screw clamps or four spring clips. Its dimensions are 313 mm in width, 239 mm in height, and 56 mm in depth, making it compact for integration into various control panels.

What is the weight of the XBTGT6330 HMI?

The product weighs approximately 2.5 kg, making it lightweight and easy to handle during installation and maintenance.

What resistance to electrostatic discharge does the XBTGT6330 provide?

The XBTGT6330 offers resistance to electrostatic discharge (ESD) up to 6 kV, compliant with IEC 61000-4-2 level 3 standards. This feature enhances the unit's reliability and durability in electrically harsh environments.

What warranty does the XBTGT6330 come with, and is it shipping-free?

The XBTGT6330 comes with a two-year MRO Electric and Supply warranty, ensuring support and protection for your investment. Additionally, MRO Electric offers free shipping for this product, making it convenient and cost-effective to acquire.

Does the XBTGT6330 have a built-in real-time clock?

Yes, the XBTGT6330 includes a built-in real-time clock, which is crucial for time-sensitive operations and system monitoring. It ensures accurate time stamping of events and data.
