| Part Number | 140CPU65260 |
| Manufacturer | Schneider Electric |
| Type | CPUs |
| Model # | 140-CPU-652-60 |
| Warranty | 2 Year |
| Marking | CE |
| Product or component | Unity processor |
| Clock frequency | 266 MHz |
| Number of slots | 10 |
| 16 | |
| 2 | |
| 4 | |
| 6 | |
| Number of racks | 2 - local rack(s) |
| Number of distributed I/O station | 63 station(s) - 1 rack(s) - 1 distributed network(s) |
| Number of remote I/O station | 31 - 2 remote rack(s) |
| Discrete I/O number | 8000 inputs, 8000 outputs - distributed - per network |
| 31744 inputs, 31744 outputs - remote | |
| Unlimited (26 slots max) - local | |
| Analogue I/O number | Unlimited (26 slots max) - local |
| 500 inputs, 500 outputs - distributed - per network |
| 1984 inputs,1984 outputs - remote | |
| Application specific I/O | Accurate time stamping |
| Counter | |
| High-speed interrupt inputs | |
| Serial link | |
| Number of optional modules | 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | Unlimited (AS-Interface) - local |
| 6 (Profibus DP) - local | |
| 6 (Modbus Plus) - local | |
| 6 (Ethernet TCP/IP) - local | |
| 4 (AS-Interface) - remote | |
| 2 (AS-Interface) - distributed | |
| 1 (USB) | |
| 1 (Modbus) - RS232/485 Modbus/ASCII | |
| Integrated connection type | 1 Ethernet TCP/IP |
| 1 Modbus | |
| 1 Modbus Plus | |
| 1 USB | |
| Checks | Process control |
| Memory description | Internal RAM 3072 kB |
| Expandable 8 MB - file storage with PCMCIA card | |
| Expandable 7168 kB - program with PCMCIA card | |
| Switch function | Key switch memory port on/off |
| Application structure | 4 auxiliary tasks |
| 32 timer interrupt tasks | |
| 128 interrupt tasks | |
| 128 I/O interrupt tasks | |
| 1 periodic fast task | |
| 1 cyclic/periodic master task | |
| Execution time per instruction | 0.4...0.5 µs floating points |
| 0.0525...0.075 µs Boolean | |
| 0.045...0.06 µs on word | |
| 0.045...0.06 µs on fixed-point arithmetic | |
| Execution time for 1 K instruction | 10.28 100 % Boolean |
| 10.07 65 % Boolean and 35 % numerical | |
| System overhead | 1 ms - master task |
| 0.2 ms - fast task | |
| Bus current requirement | 2760 mA |
| Local signalling | 1 LED red for Ethernet collision |
| 1 LED green for Ethernet activity (COM) |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 140CPU65260 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 140CPU65260 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 140CPU65260, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty 140CPU65260 for credit when ordering from MRO Electric
Schneider Electric introduces the 140CPU65260, a cutting-edge Unity processor designed to deliver unparalleled performance and versatility in industrial automation applications.
At the heart of the 140CPU65260 lies a powerful Unity processor, boasting a clock frequency of 266 MHz. This processor empowers users with exceptional processing capabilities, ensuring rapid execution of complex control algorithms and facilitating seamless integration into demanding industrial environments.
With support for up to 10 slots, including 16 discrete I/O slots, two analog I/O slots, and four application-specific I/O slots, the 140CPU65260 offers unmatched flexibility in I/O configuration. Whether handling discrete or analog signals or implementing specialized functions such as accurate time stamping and high-speed interrupt inputs, this processor provides the versatility required to address diverse application requirements.
Equipped with extensive network connectivity options, the 140CPU65260 facilitates seamless communication across distributed systems. With support for up to 63 distributed I/O stations and 31 remote I/O stations, users can scale their network infrastructure to accommodate evolving operational needs while maintaining optimal performance and reliability.
Schneider Electric offers a range of optional modules, including Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max, allowing users to enhance the functionality and connectivity of their systems. Whether implementing advanced communication protocols or integrating additional I/O modules, these optional modules offer flexibility and expandability to meet the demands of diverse industrial applications.
The 140CPU65260 features a comprehensive memory architecture, including 3072 kB of internal RAM and expandable file and program storage via PCMCIA cards. This enables users to store and execute complex control programs while ensuring efficient memory management and optimized system performance.
Designed with robust system integrity in mind, the 140CPU65260 incorporates a range of features to ensure reliable operation in demanding industrial environments. From key switch memory port control to extensive diagnostic capabilities, this processor offers peace of mind, allowing users to focus on maximizing productivity and efficiency.
The 140CPU65260 is designed to cater to a wide range of industrial automation applications, including process control, manufacturing automation, machine control, and more. Its versatile I/O configuration and robust performance make it suitable for various industries and applications.
The processor offers extensive network connectivity options, including Ethernet TCP/IP, Modbus, Modbus Plus, and USB. These connectivity options enable seamless integration into existing industrial networks and facilitate communication with other devices and systems.
Yes, the Unity processor boasts a powerful clock frequency of 266 MHz, allowing it to execute complex control algorithms and tasks with precision and efficiency. Additionally, its memory architecture and optional expansion capabilities provide ample resources for storing and executing advanced control programs.
Schneider Electric has designed the 140CPU65260 with robust system integrity features, including key switch memory port control, extensive diagnostic capabilities, and built-in redundancy options. These features help ensure reliable operation in demanding industrial environments, minimizing downtime and enhancing productivity.
