Siemens 6AV2124-0JC01-0AX0

Siemens 6AV2124-0JC01-0AX0 Product Features

The Siemens 6AV2124-0JC01-0AX0 is a state-of-the-art human-machine interface (HMI) designed for industrial applications requiring efficient monitoring and control. As part of Siemens’ Comfort Panel series, this HMI combines a high-resolution display, extensive connectivity options, and robust construction, making it an ideal solution for automation environments. Its seamless integration with industrial networks, long-term durability, and intuitive user interface make it a go-to choice for operators aiming to streamline processes and reduce downtime.

With compliance with international standards and a user-friendly interface, the device ensures high operational reliability and ease of use—perfect for manufacturing floors, process control environments, and other mission-critical industrial settings.

Display and User Interface

The 6AV2124-0JC01-0AX0 features a 9-inch TFT display designed for clear, high-quality visual output in challenging industrial conditions. Supporting 16.7 million colors, the display ensures accurate color representation for graphics, charts, and process diagrams. This high-quality image reproduction helps operators quickly interpret visual data, improving decision-making in real-time.

Its display width of 195 mm and height of 117 mm offers ample viewing space for complex screen layouts. The dimmable backlight allows operators to fine-tune brightness based on ambient lighting, enhancing both usability and eye comfort.

The touchscreen supports precise inputs, even when operators are wearing industrial gloves. With an integrated onscreen keyboard, navigation and command input are straightforward, reducing the learning curve for new users. This combination of features supports faster operator response times and minimizes the likelihood of operational errors.

Power and Memory

This Siemens 6AV2124-0JC01-0AX0 HMI operates on a 24V DC power supply with a rated power consumption of just 18W, striking a balance between performance and energy efficiency. In high-demand environments where equipment runs continuously, this low power consumption contributes to reduced operating costs.

Internally, the device features both Flash and RAM, with 12 MB of user data storage. This memory allocation supports rapid data processing, smooth screen transitions, and fast access to saved configurations. Whether storing diagnostic logs, trend data, or complex project files, the device maintains responsiveness even under heavy workloads.

Connectivity and Communication

Designed for seamless integration into industrial networks, the Siemens 6AV2124-0JC01-0AX0 offers multiple interface options. It includes RS 485, RS 422, USB, and USB Mini B ports, along with SD card slots for additional storage and data transfer capabilities. The device supports various communication protocols, including PROFINET, IRT, MRP, PROFIBUS, and MPI. These protocols allow flexible connectivity with multiple automation systems, making them highly adaptable to different industrial setups.

Mounting and Protection

Installation flexibility is critical for many plant environments, and the 6AV2124-0JC01-0AX0 accommodates both portrait and landscape mounting orientations. This adaptability allows the device to fit seamlessly into various control panel layouts.

The IP65-rated front panel ensures protection from dust ingress and low-pressure water jets, making it suitable for washdown areas and dusty manufacturing zones. The IP20-rated rear is designed for enclosed installation, offering basic protection when mounted within a cabinet or panel enclosure.

Compliance and Warranty

The 6AV2124-0JC01-0AX0 meets multiple international standards, including CE, KC, cULus, and RCM certifications. These certifications ensure compliance with industry safety and performance regulations. It comes with a 2-year warranty from MRO Electric and Supply, providing users with peace of mind regarding its reliability and durability.

6AV2124-0JC01-0AX0 Product Specifications

Engineered for performance and designed for demanding industrial environments, the Siemens 6AV2124-0JC01-0AX0 offers a robust set of technical specifications:

• Manufacturer: Siemens
• Model Number: 6AV2124-0JC01-0AX0
• Series: Comfort Panel
• Display: 9-inch TFT, 16.7 million colors
• Display Dimensions: 195 mm width x 117 mm height
• Backlight: Dimmable
• Touchscreen: Yes, with onscreen keyboard
• Power Supply: 24V DC
• Power Consumption: 18W
• Memory: Flash and RAM, 12 MB user data storage
• Interfaces: RS 485, RS 422, USB, USB Mini B, SD card slots
• Protocols Supported: PROFINET, IRT, MRP, PROFIBUS, MPI
• Mounting Options: Portrait and landscape
• Protection Rating: IP65 (front), IP20 (rear)
• Certifications: CE, KC, cULus, RCM
• Warranty: 2 years (MRO Electric and Supply)

Typical Industrial Applications

The Siemens 6AV2124-0JC01-0AX0 is engineered for a wide variety of industrial sectors, making it a highly versatile HMI. Its reliable performance, robust construction, and strong communication capabilities allow it to adapt to numerous automation requirements.

• Manufacturing Automation: Controls production lines, assembly operations, and automated inspection systems.
• Process Control: Used in industries like chemicals, pharmaceuticals, and food processing to monitor temperature, pressure, and flow rates.
• Material Handling: Ideal for conveyor systems, sorting lines, and automated warehouses.
• Energy and Utilities: Monitors and manages systems in power plants, water treatment facilities, and renewable energy sites.
• Transportation and Logistics: Integrates into control systems for cranes, loading docks, and distribution centers.

Frequently Asked Questions (FAQs) - Siemens 6AV2124-0JC01-0AX0

What is the primary function of the Siemens 6AV2124-0JC01-0AX0?

This HMI is used for industrial process monitoring and control, providing an interactive interface for operators.

What is the display size and resolution of this HMI?

It has a 9-inch TFT display with 16.7 million colors, a width of 195 mm, and a height of 117 mm.

Can the display brightness be adjusted?

Yes, the backlight is dimmable, allowing for brightness adjustment based on environmental conditions.

What power supply is required for this device?

The HMI operates on a 24V DC power supply with a power consumption of 18W.

What memory options are available?

It includes Flash and RAM, with 12 MB of user data storage.

What communication protocols are supported?

The device supports PROFINET, IRT, MRP, PROFIBUS, and MPI, ensuring compatibility with various automation systems.

What are the available connectivity options?

It includes RS 485, RS 422, USB, USB Mini B, and SD card slots for expanded connectivity.

What is the mounting format for this HMI?

The HMI can be mounted in both portrait and landscape orientations, providing installation flexibility.

How well is the device protected against dust and water?

The front panel has an IP65 rating, making it resistant to dust and water, while the rear panel has an IP20 rating.

What certifications does the device have?

It complies with CE, KC, cULus, and RCM standards, ensuring international safety and performance compliance.

The Siemens 6AV2124-0JC01-0AX0 is a versatile and robust HMI that enhances industrial automation processes. Its high-resolution display, extensive connectivity, and compliance with industry standards make it a reliable choice for operators seeking an efficient and user-friendly control interface.
