6AV6647-0AF11-3AX0

6AV6647-0AF11-3AX0

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: SIEMENS

DESCRIPTION: HMI TOUCH PANEL

PRODUCT TYPE INFO: SIMATIC 477

2 in stock
Ships Today

Free Shipping
2 Year warranty

Categories

HMI
Part Number6AV6647-0AF11-3AX0
ManufacturerSiemens
SeriesSIMATIC 477
Model #6AV66470AF113AX0
TypeHMI
Warranty2 Year
DisplayTFT
Display colors256 colors
MTBF backlighting50000 h
Screen diagonal10.4 in
Function keys8 keys
Supply voltageDC
Rating (DC)24 V
MemoryFlash / RAM
Touchscreen Yes
Inrush current0.2 A²·s
ProcessorARM, RISC 32-bit
Synchronizable Software clock Yes
ProtocolPROFINET
Ethernet ProtocolsTCP/IP, DHCP, SNMP, DCP,LLDP
Display height158.4 mm
Display width211.2 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 6AV6647-0AF11-3AX0 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 6AV6647-0AF11-3AX0 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 6AV6647-0AF11-3AX0, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 5lbs

Want it shipped today?

  • Order within the next 2 hours and 51 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 6AV6647-0AF11-3AX0 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Siemens 6AV6647-0AF11-3AX0 Overview

The Siemens 6AV6647-0AF11-3AX0 panel has a Profinet interface, a RISC 32-bit processor, and contains open-source software which is provided free of charge. The 6AV6647-0AF11-3AX0 is best mounted vertically in a landscape position.

The 6AV6647-0AF11-3AX0 uses a 24V DC power supply, however its permissible voltage can range from 19.2V to 28.8V DC. The panel is intended for operation on grounded supply networks only, it is not designed for operation on ungrounded or impedance-grounded power networks. The permitted nominal voltage of the device must conform with the local mains voltage. The mains connector must be disconnected to completely isolate the device from the mains. It is helpful if easy access is left to this area during installation. The master mains disconnect switch must be installed in the device is mounted in a switch cabinet. Always and be sure to have free and easy access to the power inlet on the device or that the safety power outlet of the building installation is freely accessible and located close the device.

How to use a 6AV6647-0AF11-3AX0

During 6AV6647-0AF11-3AX0 commissioning and its first start up, the Windows XP operating system on the Compact Flash card or hard disk is configured automatically. Follow the instructions on the screen, and then restart the system after you have entered all the necessary information and the operating system is configured. It is important to note that system startup may take longer than usual for the basic commissioning – it is normal for a blue screen to be displayed for several minutes. After this, when you switch on the PC, the user interface of the Windows XP Embedded operating system is automatically opened when the startup routine is completed.

It is advisable to create an image of your system partition after basic commissioning in order to prevent potential data loss.

The Siemens 6AV6647-0AF11-3AX0 comes with a two-year warranty.

Product Description

The 6AV6647-0AF11-3AX0 is a HMI TOUCH PANEL that is manufactured by Siemens. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. All of the products in the simatic-477 line come with a 2 year warranty from MRO Electric. We also carry HMI from other manufacturers such as FANUC and Yaskawa.
