ABE7R08S216

ABE7R08S216

Sub-Base - Soldered Electromechanical Relays Abe7 - 8 Channels - Relay 5 Mm
Available

2 Year warranty

Categories

Part NumberABE7R08S216
ManufacturerSchneider Electric
SeriesModicon Communication
Model #ABE7R08S216
TypePLC
Warranty2 Year
Tightening torque0.6 N.m (withflat Ø 3.5 mm
Range of productAdvantys Telefast ABE7
Product or component typeElectromechanical output relay sub-base
[Us] rated supply voltage24 V DC (PLC end)
Number of channels8
Relay typeLatching
Terminal block typeRemovable
Supply voltage limits<= 30 V DC (PLC end)
Polarity distributionVolt-free
Protection typeInternal fuse of 1 A (5 x 20 mm), fast blow typeat PLC end
Adjustable by external fuse, high breaking capacity typeat preactuator end
Fixing modeBy clips on 35 mm symmetrical DIN rail
By screws on solid plate with fixing kit
Width4.92 in (125 mm)
Current per channel2 A (preactuator end)
Minimum switching current2 mAat >= 5 V
Threshold tripping voltage19.2 V at 104 °F (40 °C)
Power dissipation per channel in W<= 0.3 W (PLC end)
Contacts type and composition1 NO (preactuator end)
Maximum switching voltage220 V DC conforming to IEC 60947-5-1
380 V AC 50/60 Hz conforming to IEC 60947-5-1
Electrical durability500000 cycles, maximum switching current: 1000 mAat 230 V AC-15 (preactuator end)
500000 cycles, maximum switching current: 1500 mAat 24 V DC-13 10 ms (preactuator end)
500000 cycles, maximum switching current: 2000 mAat 230 V AC-12 (preactuator end)
500000 cycles, maximum switching current: 2000 mAat 24 V DC-12 (preactuator end)
Electrical reliability2e-006
Operating time<= 4 ms between coil de-energisation and NO opening
<= 5 ms between coil energisation and NO closing
Contact bounce time<= 2 ms 1 NO
Operating rate in Hz3 Hz no load
0.5 Hz at Ie
Mechanical durability20000000 cycles
[Uimp] rated impulse withstand voltage5 kV conforming to IEC 60947-1
[Ui] rated insulation voltage2000 V
Installation categoryII conforming to IEC 60664-1

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ABE7R08S216 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ABE7R08S216 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ABE7R08S216, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 7 hours and 35 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ABE7R08S216 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Product Description

The ABE7R08S216 is a Sub-Base - Soldered Electromechanical Relays Abe7 ... that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the modicon-communication line come with a 2 year warranty from MRO Electric. We also carry Telefast from other manufacturers such as Modicon and ABB.
