TSXAEY414

Schneider Electric TSXAEY414

Rated 5/5 on 3 reviews

Rate this product


MANUFACTURER: schneider electric

DESCRIPTION: Analog Input Module

PRODUCT TYPE INFO: Modicon Premium - 4 I Multirange

9 in stock

Ships Today


Free Shipping

2 Year warranty

Part NumberTSXAEY414
ManufacturerSchneider Electric
TypeBases
Model #TSX-AEY-414
Warranty2 Year
Module formatStandard
Product or componentAnalog input module
type
Analogue input number4
Analogue input typeCurrent 4...20 mA
Resistor 0...400 Ohm
Resistor 0...3850 Ohm
Temperature probe Pt 100 2 wires
Temperature probe Pt 100 4 wires
Temperature probe Pt 1000 2 wires
Temperature probe Pt 1000 4 wires
Temperature probe Ni 1000 2 wires
Temperature probe Ni 1000 4 wires
Thermocouple thermocouple B
Thermocouple thermocouple E
Thermocouple thermocouple J
Thermocouple thermocouple K
Thermocouple thermocouple L
Thermocouple thermocouple N
Thermocouple thermocouple R
Thermocouple thermocouple S
Thermocouple thermocouple T
Thermocouple thermocouple U
Voltage - 13...63 mV
Voltage +/- 10 V
Voltage 0...10 V
Voltage +/- 5 V
Voltage 0...5 V
Voltage 1...5 V
Analog/Digital conversion16 bits
Isolation between channels2830 Vrms
Input levelLow level
Nominal read cycle time550 ms
Measurement error0.13 % of full scale 0...400 Ohm 25 °C
0.16 % of full scale 0...10 V 25 °C
0.19 % of full scale - 13...63 mV 25 °C
0.22 % of full scale 0...3850 Ohm 25 °C
0.22 % of full scale 0...5 V 25 °C
0.27 % of full scale 0...400 Ohm 0...60 °C
0.27 % of full scale +/- 10 V 25 °C
0.27 % of full scale +/- 5 V 25 °C
0.27 % of full scale 1...5 V 25 °C
0.39 % of full scale 0...10 V 0...60 °C
0.44 % of full scale - 13...63 mV 0...60 °C
0.45 % of full scale 0...5 V 0...60 °C
0.45 % of full scale 4...20 mA 25 °C
0.48 % of full scale 0...3850 Ohm 0...60 °C
0.5 % of full scale +/- 10 V 0...60 °C
0.5 % of full scale +/- 5 V 0...60 °C
0.56 % of full scale 1...5 V 0...60 °C
0.86 % of full scale 4...20 mA 0...60 °C
1 °C Ni 1000 25 °C
1.2 °C Pt 100 25 °C
1.5 °C thermocouple B external 25 °C
1.5 °C thermocouple E external 25 °C
1.5 °C thermocouple T external 25 °C
1.5 °C thermocouple U external 25 °C
1.8 °C thermocouple J external 25 °C
2 °C Ni 1000 0...60 °C
2 °C thermocouple L external 25 °C
2 °C thermocouple N external 25 °C
2.3 °C thermocouple K external 25 °C
2.4 °C Pt 100 0...60 °C
2.5 °C Pt 1000 25 °C
3.1 °C thermocouple U external 0...60 °C
3.2 °C thermocouple E external 0...60 °C
3.2 °C thermocouple T external 0...60 °C
3.2 °C thermocouple R external 25 °C
3.4 °C thermocouple S external 25 °C
3.5 °C thermocouple B external 0...60 °C
3.5 °C thermocouple B internal 25 °C
3.8 °C thermocouple J external 0...60 °C
4.1 °C thermocouple L external 0...60 °C
4.3 °C thermocouple N external 0...60 °C
4.7 °C thermocouple K external 0...60 °C
5 °C Pt 1000 0...60 °C
5.4 °C thermocouple U internal 25 °C
6 °C thermocouple N internal 25 °C
6 °C thermocouple R internal 25 °C
6.1 °C thermocouple E internal 25 °C
6.6 °C thermocouple S internal 25 °C
6.6 °C thermocouple T internal 25 °C
7.3 °C thermocouple U internal 0...60 °C
7.3 °C thermocouple J internal 25 °C
7.5 °C thermocouple L internal 25 °C
7.7 °C thermocouple R external 0...60 °C
7.8 °C thermocouple K internal 25 °C
8.1 °C thermocouple B internal 0...60 °C
8.1 °C thermocouple E internal 0...60 °C
8.5 °C thermocouple S external 0...60 °C
8.7 °C thermocouple N internal 0...60 °C
8.8 °C thermocouple T internal 0...60 °C
9.5 °C thermocouple J internal 0...60 °C
9.8 °C thermocouple L internal 0...60 °C
10.5 °C thermocouple K internal 0...60 °C
11 °C thermocouple R internal 0...60 °C
12 °C thermocouple S internal 0...60 °C
Isolation between channels and bus1780 Vrms
Isolation between channels and ground1780 Vrms
Common mode between channels415 V AC or 200 V DC
Common mode between channels and earth240 V AC or 110 V DC
Maximum overvoltage on input-30...30 V at state 1 250 Ohm
-15...15 V at state 0 250 Ohm
Electrical connectionScrew terminal block
Overcurrent-30...30 mA at state 1 250 kOhm
MarkingCE
Current consumption660 mA 5 V DC

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXAEY414 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXAEY414 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXAEY414, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 8 hours and 33 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXAEY414 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXAEY414 Overview

The TSXAEY414 is an analog input module produced by Schneider Electric, a multinational corporation specializing in energy management and automation solutions. The module is designed to accept various analog inputs, including current, voltage, and temperature probes, making it a versatile component in control and automation systems. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Bases from other manufacturers such as Modicon and ABB.

Construction

The Modicon TSXAEY414 module is constructed in a base form factor and has four analog input channels that can accept different types of inputs. The supported analog input types are current 4...20 mA, voltage -13...63 mV, voltage +/- 10 V, voltage 0...10 V, voltage +/- 5 V, voltage 0...5 V, voltage 1...5 V, and various temperature probes including Pt 100, Pt 1000, Ni 1000, and thermocouples (types B, E, J, K, L, N, R, S, and T).

Features

The TSXAEY414 module offers high accuracy in analog-to-digital conversion with a resolution of 16 bits. The isolation between channels is 2830 Vrms, providing protection against ground loops and electrical interference. The nominal read cycle time is 550 ms, which is fast enough for most applications.

The accuracy of the module Modicon TSXAEY414 depends on the input type, the temperature, and the range of the input signal. For instance, the measurement error is 0.13 % of full scale for resistor inputs in the range of 0...400 Ohm at 25°C, but it increases to 0.27 % of full scale at 60°C. For voltage inputs in the range of +/- 10 V, the measurement error is 0.27 % of full scale at 25°C and 0.5 % of full scale at 60°C. Similarly, for thermocouple inputs, the measurement error ranges from 1.5°C to 7.7°C, depending on the thermocouple type and the temperature range.

Design

The TSXAEY414 analog input module is designed to be used with Schneider Electric's Modicon Quantum automation platform, a programmable logic controller (PLC) that offers a wide range of functions and features for industrial automation. The module is compatible with the standard format used by Modicon Quantum, making it easy to integrate into existing systems.

The module is backed by a two-year warranty, which provides peace of mind to users in case of any defects or malfunctions. The warranty ensures that the module will be repaired or replaced free of charge during the warranty period, subject to the terms and conditions of the warranty.

In summary, the TSXAEY414 is a versatile and accurate analog input module that is ideal for a wide range of applications in control and automation systems. Its ability to accept various analog inputs, including temperature probes and voltage/current signals, makes it a valuable component in many industries, including manufacturing, energy, and transportation. The module's high accuracy, fast read cycle time, and isolation between channels make it a reliable and efficient solution for analog input processing. Additionally, the module's compatibility with the Modicon Quantum platform and the two-year warranty make it an attractive choice for users who value reliability and performance.
