140DDO35300C

2-year Warranty

Same Day Shipping

Schneider Electric 140DDO35300C

DISCRETE OUTPUT MODULE MODICON QUANTUM - 32 O SOLID STATE

5/5
1 rating

Available


Free Shipping

2 Year warranty

Part Number140DDO35300C
ManufacturerSchneider Electric
TypeI/O Modules
Model #140-DDO-353-00C
Warranty2 Year
Module formatStandard
Product or component typeDc discrete output module
Discrete output number32
Group of channels4 groups of 8
Discrete output logicPositive logic (source)
Addressing requirement2 output words
Discrete output voltage24 V DC
Output voltage limits19.2...30 V
Absolute maximum output56 V for 1.3 s decaying pulse
Voltage drop0.4 V 0.5 A
Maximum load current16 A per module
16 A per module
4 A per group
4 A per group
Surge current<= 5 A for 0.0005 s
Response time<= 1 ms at state 0 to state 1
<= 1 ms at state 1 to state 0
Leakage current0.4 mA 30 V
Load inductanceInductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 50 Hz
Fault indicationLoss of field power
Blown fuse
Associated fuse rating3 A each point
5 A per group
Isolation between channels and bus1780 Vrms DC for 1 minute
Isolation between group500 Vrms DC for 1 minute
Protection typeInternal output protection by 5 A fuse per group
Power dissipation1.75 W + (0.4 V x total module load current)
MarkingCE
Local signalling1 LED green bus communication is present (Active)
1 LED red external fault detected (F)
32 LEDs green input status
Bus current requirement330 mA
330 mA

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 140DDO35300C to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 140DDO35300C we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 140DDO35300C, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 22 hours and 15 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 140DDO35300C for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 140DDO35300C Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
