170ADI34000

170ADI34000

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: SCHNEIDER ELECTRIC

DESCRIPTION: Discrete Input Module - 16 Input 24 V DC

PRODUCT TYPE INFO: Modicon Momentum

21 in stock
Ships Today

Free Shipping
2 Year warranty

Categories

Part Number170ADI34000
ManufacturerSchneider Electric
SeriesModicon Communication
Model #170ADI34000
TypeIO Modules
Warranty2 Year
Width5.57 in (141.5 mm)
Range of productModicon Momentum automation platform
Product or component typeDiscrete inputs base DC
Group of channels1 group of 16 inputs
Discrete input number16 IEC 1131-2 Type 1
Discrete input voltage24 V DC
Protective treatmentTC
Discrete input logicPositive
Input voltage limits24 V
Voltage range- 3...30 V
Voltage state 0 guaranteed-3...5 V
Voltage state 1 guaranteed11...30 V
Current state 0 guaranteed<= 1.2 mA
Current state 1 guaranteed>= 2.5 mA
Input resistance4 kOhm
Response time2.2 ms from state 0 to state 1
3.3 ms from state 1 to state 0
Isolation between channels and bus500 V AC
Power dissipation3 W typical
5 W maximum
Terminals description PLC n°1(13)IN_DIS#13
(2)IN_DIS#2
(3)IN_DIS#3
(M-)PW_NEG
(5)IN_DIS#5
(1)IN_DIS#1
(15)IN_DIS#15
(L+)PW_POS
(8)IN_DIS#8
(7)IN_DIS#7
(14)IN_DIS#14
(12)IN_DIS#12
TB
(16)IN_DIS#16
(4)IN_DIS#4
(9)IN_DIS#9
(11)IN_DIS#11
(10)IN_DIS#10
(6)IN_DIS#6
MarkingCE
Local signalling16 LEDs channel status
Current consumption<= 250 mA 24 V DC
Depth1.87 in (47.5 mm)
Height5.57 in (141.5 mm)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 170ADI34000 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 170ADI34000 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 170ADI34000, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 4 hours and 12 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 170ADI34000 for credit when ordering from MRO Electric

Additional Information

Schneider Electric 170ADI34000 Overview

This discrete input module from Schneider Electric’s highly regarded Modicon Communication series comes backed with a one-year warranty from MRO Electric & Supply. As one of Schneider Electric’s Green Premium products, the 170ADI34000 input module has already met strict requirements and certifications for environmental protection and user safety before it gets to you.

To start out, this discrete input module, along with others from this series, can either be panel mounted or DIN rail mounted thanks to the simple but strong locking tab feature. From start to finish this I/O module is designed with you in mind. Say goodbye frustrating and confusing mount procedures!

One of the best things about the 170ADI34000 input module is the automatic communication between the input module and the adapter base that makes for a more streamlined process and saves you time. Along with that, customized LED displays provide timely and pertinent information about the status of your input module for ease of use.

Each and every module also has three terminal connectors for your convenience, enabling you to connect it with whatever compatible parts you need to get the job done right the first time. Additionally, if you are in need of a busbar slot, you are in luck! This discrete input module comes fully equipped with a busbar slot, all you need to do is order the part separately and you are on your way. Attaching the busbar sets you up to support three- and four-wire field devices with ease
